Airtac ATE Single Acting Guided Compact Cylinder ATE16X10B
$27.67
Regular price
$35.17
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ATE16X10B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 21287 standard for enhanced cross-brand installation compatibility;
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
Installation tip:
For vertical mounting, maintain ≥0.3mm alignment tolerance between rod end and load.
Lubricate every 500,000 cycles under normal operation. Maximum side load: 5N.
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
AirTAC ATE16X10B Single-Acting Compact Cylinder Specifications
- Model: ATE16X10B
- Type: Single-acting spring return (push type)
- Bore size: 16mm
- Stroke: 10mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard) or NPT1/8 optional
- Cushioning: Adjustable rubber buffer
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel (SUS304)
- Seal type: NBR rubber seals (oil & heat resistant)
- Mounting style: Basic type (MF1) with multiple accessory options
- Weight: 0.23kg ±3%
- Dimensions:
- Length: 74mm (fully retracted)
- Width: 32mm (max body width)
- Height: 32mm (including mounting tabs)
- Protection rating: IP54 (standard), IP67 optional
- Theoretical thrust: 31.4N @0.5MPa
Ultra-compact cylinder optimized for space-constrained automation systems. Features a non-rotating piston rod with precision guide for stable linear motion. The nickel-plated end caps provide corrosion resistance in humid environments. Requires filtered air (5-40μm) with ISO VG32 or equivalent lubricant.
Typical Applications:
- PCB handling robots for component insertion
- Medical device locking mechanisms
- Conveyor gate actuators in food packaging
- Semiconductor wafer clamping systems
- Automated test equipment position stops
Installation tip:
For vertical mounting, maintain ≥0.3mm alignment tolerance between rod end and load.
Lubricate every 500,000 cycles under normal operation. Maximum side load: 5N.
| Property | Property Value |
|---|---|
| sku | ATE16X10B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
