Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF30010AW
AirTAC B52-GF30010AW Copper-Free Air Treatment Unit Specifications
- Model: B52-GF30010AW
- Type: 3-in-1 filter-regulator-lubricator (FRL) with copper-free construction
- Filtration rating: 5μm (replaceable paper element)
- Maximum flow capacity: 3000 L/min (ANR)
- Operating pressure range: 0.05-1.0 MPa
- Inlet/Outlet ports: PT1" (G1" optional)
- Body material: Die-cast aluminum with epoxy coating
- Seal material: NBR (Nitrile rubber)
- Ambient temperature range: -5℃ to 60℃
- Pressure gauge: 1/8" NPT interface, 0-1.6 MPa range
- Drain type: Semi-automatic float drain
- Weight: 0.65 kg (without filter element)
- Dimensions: 130mm(W) × 70mm(D) × 120mm(H)
- Condensate capacity: 15cc (bowl volume)
- Air viscosity range: 10-150 cSt
Copper-free FRL unit designed for compressed air systems requiring strict metal contamination control. Features corrosion-resistant aluminum construction with triple-stage processing: particulate filtration (5μm), pressure regulation (±0.02MPa stability), and optional lubrication (oil-fog type). The bowl includes safety shield and blowdown lock mechanism.
- Semiconductor manufacturing cleanrooms
- Food & beverage pneumatic lines (FDA-compliant version available)
- Medical gas handling systems
- Copper-sensitive chemical processes
- Laboratory analytical instrument air supply
Installation note:
Install vertically with arrow marking aligned to airflow direction.
Replace filter element every 6 months or when differential pressure exceeds 0.1MPa.
For lubrication function, maintain oil level between 1/3 to 2/3 of sight glass.
- Pull up regulator knob to unlock
- Rotate clockwise to increase pressure (view gauge)
- Push down knob to lock setting
- Verify stability under load conditions
| Property | Property Value |
|---|---|
| sku | B52-GF30010AW |
