Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF30015MW
The AirTAC Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF30015MW is a genuine G-series air filter. It separates condensed water and filters particulate from the compressed-air line through a 5 µm element, with PT1/2" ports and a manual drain. A filter does not set downstream pressure — pair it with a GR regulator, or use a GFR filter regulator, when pressure control is needed.
- TypeAir filter
- Port sizePT1/2"
- Filtering grade5 µm
- DrainManual drain
- Inlet pressure0 - 0.9 MPa (0 - 131 psi)
- Bowl materialPC
- ThreadPT
- BracketMounting bracket included
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF30015MW
The AirTAC GF30015MW is a G-series compressed-air filter: filtration only - it removes water and particulate, with no regulation and no lubrication. This configuration is size 300 with a 1/2 in PT (the standard thread) port, a polycarbonate manual-drain bowl, mounting bracket included, and the fine 5 um element (W) in place of the standard 40 um. Maximum inlet pressure for the manual-drain version is 0.9 MPa.
It is a genuine AirTAC part from the GF family, which covers sizes 200 to 600 with port, thread (PT/G/NPT), drain and element options, including the same 5 um grade without a bracket. AirTAC publishes flow as curves rather than a single rated figure, so we confirm the datasheet and flow figures on request.
Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF30015MW Technical Specifications
| Model | Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF30015MW |
|---|---|
| Series | GF300 air filter |
| Port size | PT1/2" (PT thread) |
| Filtering grade | 5 µm |
| Drain type | Manual drain |
| Bracket | Mounting bracket included |
| Fluid | Compressed air |
|---|---|
| Inlet pressure | 0 - 0.9 MPa (0 - 131 psi) |
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Bowl material | PC |
| Feature | Low pressure loss |
Specifications follow the official AirTAC G-series air-preparation data. The inlet-pressure band is set by the drain type: automatic and differential-pressure drains run 0.15 - 1.0 MPa, a manual drain runs 0 - 0.9 MPa. Air must not freeze in the unit. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF30015MW
| GF300 | G-series air filter, 300 body — sets the port range. |
|---|---|
| 15 | Port size PT1/2". This body offers 08 = PT1/4", 10 = PT3/8", 15 = PT1/2". |
| M | Drain: Manual drain. Options are differential (blank), automatic (A) or manual (M). |
| (blank) | Mounting bracket included. A bracket ships by default; J orders it without. |
| W | Filtering grade 5 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
Field order is size, port, drain, bracket, grade, thread — a blank position takes the default. Example: GF300-10AJW is a 300 body, PT3/8", automatic drain, no bracket, 5 µm element, PT thread.
Size Class
- GF200PT1/8" - PT1/4"
- GF300PT1/4" - PT1/2"
- GF400PT3/8" - PT1/2"
- GF600PT3/4" - PT1"
A larger body carries a larger port and passes more air at the same pressure drop. AirTAC publishes flow only as curves, so size the body from your peak demand with headroom rather than from a single rated figure. The GF600 uses an aluminium-alloy bowl; the 200, 300 and 400 bodies use PC.
| This model | GF300 · PT1/2" · 5 µm |
|---|---|
| One size down | GF200 |
| One size up | GF400 |
| Line order | Filter first, then regulator, then lubricator |
Where the Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF30015MW Is Used
Injection moulding machine air circuits
Installed on the compressed-air feed to an injection press's core-pull, ejection and valve-gate circuits, the 5 um element protects the mould-side valves from fine contamination and carried-over water.
Food packaging line actuation air
Mounted at the supply to a packaging machine's filler and sealer cylinders, it delivers cleaner air to the fast-cycling valves and keeps condensate out of product-adjacent pneumatics.
Process valve actuation panel
Fitted in the air supply panel that operates pneumatically actuated process valves, it supplies fine-filtered air to positioners and pilot solenoids mounted where a bracket keeps the unit secured.
Is the Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF30015MW the Right Filter?
This is the fine-filtration (5 um, W) size 300 filter at 1/2 in PT with the mounting bracket supplied - the bracketed choice when you want to wall- or panel-mount it at the point of use. Manual drain suits a location an operator visits routinely; for unattended or enclosed positions step to the automatic or differential-pressure drain variants. Keep the 5 um grade for downstream equipment that needs it; the standard 40 um element is the economical choice for general air. G and NPT threads are order options if PT does not suit the piping.
Because flow is published as curves rather than a single rating, ask us to confirm the datasheet sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/2" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain: differential, automatic or manual
- ✓ Manual drain caps inlet at 0.9 MPa
- ✓ Thread PT, G (BSPP) or NPT
- ✓ Bracket needed, or order with J
Installation & Maintenance Notes
- check Mount vertically, bowl down, and follow the airflow arrow.
- check Put the filter first in the air-preparation line.
- check Keep inlet pressure within 0 - 0.9 MPa (0 - 131 psi).
- check Drain condensate before the bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Replace the 5 µm element when pressure loss rises.
The PC bowl must not be cleaned with solvents or exposed to synthetic oils that attack polycarbonate — wipe it with a dry cloth. A filter removes water and particulate only; it does not regulate pressure or add lubrication.
Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF30015MW FAQ
No - AirTAC publishes flow for the GF series as pressure-drop curves rather than one rated number, so we do not state a figure here. Send us your pressure and air consumption and we will confirm the sizing from the datasheet on request.
Manual (this model, code M) means an operator opens the drain periodically - dependable and low-cost where the filter is accessible. Automatic (A) bleeds condensate by itself, and the differential-pressure drain (blank) responds to the pressure across the element. Pick based on access and how often the line runs; all three are catalogue choices for the GF300.
