Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF40010W
AirTAC B52-GF40010W Non-Copper Air Source Treatment Unit Specifications
- Model: B52-GF40010W
- Type: Filter-Regulator-Lubricator (FRL) combo unit with copper-free construction
- Port size: G1/4 (ISO standard)
- Operating pressure: 0.15–0.85 MPa
- Maximum flow: 4000 L/min (ANR)
- Filtration grade: 5 μm (auto-drain version)
- Pressure gauge: 1/8" dial type (0-1.0 MPa scale)
- Adjustment knob: Lockable rotary design with ±2% accuracy
- Body material: Aluminum alloy (copper-free anodized finish)
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -5℃ to 60℃ (non-freezing conditions)
- Weight: 820g ±3% (without lubricant)
- Dimensions: 165mm(L) × 75mm(W) × 78mm(H) (including gauge)
- Mounting: Bracket slot spacing 35mm (ISO 4414 compatible)
- Oil capacity: 180cc (maximum lubricant fill)
Triple-function pneumatic conditioning unit engineered for copper-sensitive environments. Features integrated 5μm particulate filtration, precision pressure regulation (±0.02 MPa stability), and adjustable oil mist lubrication (0-8 drops/min). The aluminum construction prevents copper contamination in semiconductor/pharmaceutical applications.
- Semiconductor wafer handling robotics
- Medical gas line conditioning systems
- Food-grade pneumatic packaging lines
- Marine equipment (saltwater corrosion resistance)
- High-purity painting systems
Installation protocol:
Install downstream of air dryer with minimum 300mm straight piping before unit.
Lubricator should be positioned 5-8m upstream from actuators. Drain valve requires
weekly maintenance in humid environments.
| Property | Property Value |
|---|---|
| sku | B52-GF40010W |
