Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF60020AJW
AirTAC B52-GF60020AJW Non-Copper Air Source Treatment Unit Specifications
- Full model: B52-GF60020AJW
- Series: B52-GF (Copper-Free Design)
- Function: Integrated FRL (Filter-Regulator-Lubricator)
- Port size: G1/2 (BSPP thread)
- Maximum pressure: 1.6 MPa
- Operating pressure range: 0.15–1.0 MPa
- Flow capacity: 6000 L/min (ANR)
- Filtration grade: 5 μm (40μm optional with different filter element)
- Adjustable pressure range: 0.05–0.85 MPa
- Oil cup capacity: 70 cm³
- Body material: Aluminum alloy (copper-free)
- Seal material: HNBR (Hydrogenated Nitrile)
- Ambient temperature: -5℃ to 60℃ (no freezing)
- Weight: 0.82 kg (empty oil cup)
- Dimensions: 156mm(L) × 75mm(W) × 128mm(H)
- Mounting: Bracket type (horizontal/vertical installation)
- Pressure gauge: Built-in 1/8" dial gauge (0-1.0 MPa scale)
- Drain type: Manual drain button with splash guard
Triple-function compressed air treatment unit specifically engineered for copper-sensitive environments. Features aluminum alloy construction with corrosion-resistant surface treatment, preventing copper particle contamination. The integrated bypass design maintains airflow during filter maintenance.
- Semiconductor manufacturing cleanrooms
- Copper-free pneumatic systems in chemical plants
- Food processing automation lines (FDA-compliant)
- Lithium battery production equipment
- Medical gas control systems
Installation protocol:
Install downstream of air compressor (minimum 500mm distance from heat sources).
Lubricator should be positioned last in the FRL sequence. Perform weekly drainage
and replace filter element every 2000 operational hours. Use ISO VG32 turbine oil
for lubrication.
Critical note:
Strictly prohibit using silicone-based lubricants. Maintain oil level between
1/3 to 2/3 of cup capacity. Never operate without filter element installed.
