Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF60025MW
The AirTAC Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF60025MW is a genuine G-series air filter. It separates condensed water and filters particulate from the compressed-air line through a 5 µm element, with PT1" ports and a manual drain. A filter does not set downstream pressure — pair it with a GR regulator, or use a GFR filter regulator, when pressure control is needed.
- TypeAir filter
- Port sizePT1"
- Filtering grade5 µm
- DrainManual drain
- Inlet pressure0 - 0.9 MPa (0 - 131 psi)
- Bowl materialAluminium alloy
- ThreadPT
- BracketMounting bracket included
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF60025MW
The GF60025MW is an AirTAC GF-series air filter dedicated to removing water and particulate from compressed air - it contains no regulator and no lubricator. This size 600 unit has a 1 in. PT thread, the fine 5 um element (W suffix), a manual drain operated by hand, and a mounting bracket included as standard. Because it is a manual-drain filter, its maximum inlet pressure is 0.9 MPa. The 600-size bowl is aluminium alloy, and the operating range is -5 to 70 C, non-freezing.
This is a genuine AirTAC part distributed in the US market. The GF range covers sizes 200 to 600, with differential-pressure, automatic or manual drains, 40 um or 5 um (W) elements, and PT, G (BSPP) or NPT thread options. Since AirTAC publishes flow only as curves rather than a single rating, we confirm flow and datasheet figures for your application on request.
Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF60025MW Technical Specifications
| Model | Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF60025MW |
|---|---|
| Series | GF600 air filter |
| Port size | PT1" (PT thread) |
| Filtering grade | 5 µm |
| Drain type | Manual drain |
| Bracket | Mounting bracket included |
| Fluid | Compressed air |
|---|---|
| Inlet pressure | 0 - 0.9 MPa (0 - 131 psi) |
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Bowl material | Aluminium alloy |
| Feature | Low pressure loss |
Specifications follow the official AirTAC G-series air-preparation data. The inlet-pressure band is set by the drain type: automatic and differential-pressure drains run 0.15 - 1.0 MPa, a manual drain runs 0 - 0.9 MPa. Air must not freeze in the unit. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF60025MW
| GF600 | G-series air filter, 600 body — sets the port range. |
|---|---|
| 25 | Port size PT1". This body offers 20 = PT3/4", 25 = PT1". |
| M | Drain: Manual drain. Options are differential (blank), automatic (A) or manual (M). |
| (blank) | Mounting bracket included. A bracket ships by default; J orders it without. |
| W | Filtering grade 5 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
Field order is size, port, drain, bracket, grade, thread — a blank position takes the default. Example: GF300-10AJW is a 300 body, PT3/8", automatic drain, no bracket, 5 µm element, PT thread.
Size Class
- GF200PT1/8" - PT1/4"
- GF300PT1/4" - PT1/2"
- GF400PT3/8" - PT1/2"
- GF600PT3/4" - PT1"
A larger body carries a larger port and passes more air at the same pressure drop. AirTAC publishes flow only as curves, so size the body from your peak demand with headroom rather than from a single rated figure. The GF600 uses an aluminium-alloy bowl; the 200, 300 and 400 bodies use PC.
| This model | GF600 · PT1" · 5 µm |
|---|---|
| One size down | GF400 |
| Line order | Filter first, then regulator, then lubricator |
Where the Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF60025MW Is Used
Bottling line fill-head air
Bracket-mounted on the machine frame, the 5 um element conditions air feeding fill-head actuators and gripper cylinders on a high-speed bottling conveyor.
Robotic welding cell services
Panel-mounted beside the robot controller, the filter cleans the air feeding weld-gun clamp cylinders and tool-change locking rings on the welding cell.
Textile air-jet loom supply
At the loom air manifold, the GF60025MW removes moisture and fine dirt before air reaches the jet nozzles, helping keep weaving operations consistent.
Is the Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF60025MW the Right Filter?
The included bracket lets you fix the filter to a frame or panel instead of hanging it on the pipe - worth specifying on machines where the 1 in. piping would otherwise carry the unit's weight. The 5 um element suits finer-protection duties; use the standard 40 um grade where coarse filtration is enough. Manual drain suits attended installations; choose automatic (A) or differential-pressure drain where access is awkward. Size 600 with 1 in. PT ports matches 1 in. headers; smaller sizes suit lower flows. Thread is PT standard with G and NPT as catalogue options. Flow is published as curves, not a single rating, so ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain: differential, automatic or manual
- ✓ Manual drain caps inlet at 0.9 MPa
- ✓ Thread PT, G (BSPP) or NPT
- ✓ Bracket needed, or order with J
Installation & Maintenance Notes
- check Mount vertically, bowl down, and follow the airflow arrow.
- check Put the filter first in the air-preparation line.
- check Keep inlet pressure within 0 - 0.9 MPa (0 - 131 psi).
- check Drain condensate before the bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Replace the 5 µm element when pressure loss rises.
The aluminium-alloy bowl on the GF600 suits harsher environments than a PC bowl. A filter removes water and particulate only; it does not regulate pressure or add lubrication.
Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF60025MW FAQ
There is no single rated-flow figure to quote: AirTAC publishes filter performance as curves against pressure and flow. Give us your line pressure and air demand and we will confirm the relevant flow and datasheet figures for this model on request.
No. On the GF60025MW the absence of a J suffix means the mounting bracket is included, so the unit can be secured to a frame or panel rather than supported by the pipework. If you specifically do not want a bracket, order the GF60025MJW instead.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
Related AirTAC Air-Preparation Units
Request a Quote for Airtac B52-GF Copper-Free Pneumatic Air Treatment Component B52-GF60025MW
Send us the quantity, thread type (PT / G / NPT) and destination. We confirm price, availability and lead time — usually within 7-8 hours.
