Airtac HRQ Rotary Cylinder HRQ30
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ30 Rotary Cylinder Technical Specifications
- Model: HRQ30
- Type: Double-acting rotary actuator
- Torque output: 3.0 Nm (at 0.6 MPa)
- Rotation angle: 0-190° adjustable
- Operating pressure: 0.2-0.8 MPa
- Port size: M5x0.8 (standard), G1/8 optional
- Rotation speed: 30-120 rpm (air pressure dependent)
- Temperature range: -10℃ to 70℃
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR
- Weight: 1.2 kg ±5%
- Dimensions: 100mm(L) × 80mm(W) × 80mm(H)
- Mounting pattern: ISO 21287 compliant
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (Daphne AL type grease)
The HRQ30 features a precision-ground helical gear mechanism with zero-backlash design, offering repeat positioning accuracy within ±0.5°. Its compact profile integrates dual cushioning adjustment screws for smooth angular deceleration. The hardened steel shaft (HRC 45-50) withstands radial loads up to 150N. Requires 5μm filtered compressed air with 1-10 cSt viscosity oil mist lubrication for optimal performance.
- Automated part positioning in assembly lines
- 90° workpiece flipping in machining centers
- Valve actuation in process control systems
- Pallet rotation in packaging machinery
- Camera/Sensor turret positioning
Installation tip:
Align mounting surface within 0.1mm flatness tolerance. Use dynamic seal-friendly lubricants only.
For vertical mounting, install exhaust mist separator to prevent oil accumulation in gear chamber.
| Property | Property Value |
|---|---|
| sku | HRQ30 |
| Side Port | M5×0.8 |
| Front Port | PT1/8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Fixed Cushion |
| Specification | 30 |
