Airtac HRQ Rotary Cylinder HRQ30A
$257.52
Regular price
$265.02
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HRQ30A
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HRQ Rotary Cylinder Technical Specifications:
1. Gear-rack mechanism ensures smooth operation;
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
Installation note:
Mount using M5x0.8 mounting holes (4 places). Allow ±2° alignment tolerance during installation.
Lubricate pivot bearings every 500,000 cycles under continuous operation.
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Series Rotary Cylinder HRQ30A Specifications
- Model: HRQ30A
- Type: Double-acting rotary actuator
- Rotation angle: 0-190° adjustable (standard 90° or 180° preset)
- Torque output: 1.2 N·m @ 0.63 MPa | 0.96 N·m @ 0.5 MPa
- Operating pressure: 0.1-0.7 MPa
- Port size: PT1/8 (G1/8 optional)
- Piston diameter: 30 mm
- Weight: 1.85 kg ±2%
- Dimensions: 98mm(L) × 76mm(W) × 76mm(H)
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR (-20℃ to 100℃)
- Rotation accuracy: ±1° (with adjustable stopper)
- Max angular velocity: 120°/sec @ 0.5 MPa
- Protection rating: IP40 (dust resistant)
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil if needed)
Precision rotary cylinder with dual adjustable mechanical stops and anti-rotation pins. Features chromium-plated piston rod and built-in cushioning for smooth angular positioning. Requires 5μm filtered dry air (dew point -10℃ below ambient).
Typical Applications:
- 90° part flipping in assembly lines
- Indexing table positioning systems
- Robotic end-effector orientation
- Clamping fixture rotation (CNC machining)
- Conveyor diverter gate control
Installation note:
Mount using M5x0.8 mounting holes (4 places). Allow ±2° alignment tolerance during installation.
Lubricate pivot bearings every 500,000 cycles under continuous operation.
| Property | Property Value |
|---|---|
| sku | HRQ30A |
| Side Port | M5×0.8 |
| Front Port | PT1/8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Hydraulic Shock Absorber Cushioning |
| Specification | 30 |
