Airtac HRQ Rotary Cylinder HRQ50
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ50 Rotary Cylinder Technical Specifications
- Model: HRQ50
- Rotation angle: 0°-190° adjustable
- Torque range: 0.5-5.0 Nm (adjustable via air pressure)
- Operating pressure: 0.1-0.8 MPa
- Air port size: PT1/4 (G1/4 optional)
- Piston diameter: 50mm
- Rotation speed: 90° in 0.3-0.8s (at 0.5MPa)
- Weight: 2.8 kg ±5%
- Dimensions: 150mm(L) × 100mm(W) × 100mm(H)
- Body material: Aluminum alloy (hard anodized)
- Seal material: NBR/PU combination
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubricated (ISO VG32 equivalent)
- Repeat accuracy: ±0.2°
- Mounting options: Front flange/Foot mount
High-precision rotary actuator with dual-piston torque amplification design, featuring adjustable mechanical stops and built-in cushioning. The HRQ50's corrosion-resistant construction and IP54 protection make it ideal for harsh environments. Requires 5μm filtered dry air (dew point -20℃ below ambient).
- Automated part positioning in CNC pallet changers
- 90° workpiece flipping in assembly lines
- Valve actuation in chemical processing equipment
- Camera/sensor turret rotation in inspection systems
- Packaging machine lid closing mechanisms
- Semiconductor wafer handling robots
Installation note:
Always install shock absorbers when exceeding 180° rotation.
Maintain 0.5mm minimum clearance between stopper plates during adjustment.
Use M6x1.0 mounting screws with 12N·m tightening torque.
| Property | Property Value |
|---|---|
| sku | HRQ50 |
| Side Port | M5×0.8 |
| Front Port | PT1/8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Fixed Cushion |
| Specification | Bore Size: 50mm |
