Airtac HRQ Rotary Cylinder HRQ50A
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Rotary Cylinder HRQ50A Technical Specifications
- Model: HRQ50A (ISO 15552 compliant)
- Bore size: Ø50 mm
- Rotation angle: 0-190° adjustable
- Torque output: 12.5 Nm @ 0.63 MPa
- Operating pressure: 0.15-1.0 MPa
- Air port size: G1/8 (NPT1/4 optional)
- Piston material: Aluminum alloy with hard anodizing
- Seal type: HNBR (Hydrogenated Nitrile) wiper seals
- Temperature range: -10℃ to 80℃
- Weight: 2.8 kg (dry, without accessories)
- Dimensions: 165mm(L) × 78mm(W) × 78mm(H)
- Rotation accuracy: ±0.5° (with adjustable stopper)
- Cushioning: Adjustable pneumatic cushioning
- Mounting: Standard ISO 15552 mounting pattern
- Protection class: IP54 (standard), IP67 optional
The HRQ50A rotary actuator combines high torque density with precision angular control, featuring dual-piston rack-and-pinion drive for smooth rotation. Its hardened stainless steel shaft and dual-bearing design ensure minimal backlash during repetitive operations. Requires 5-40μm filtered compressed air with ISO VG32 lubricator.
- Automated welding positioners (360° part rotation)
- CNC machine tool clamping/unclamping mechanisms
- Packaging line product orientation systems
- Automotive assembly line component flipping stations
- Solar panel tracking system articulation
Installation guidelines:
Mount using M6x12mm Class 8.8 bolts with anti-vibration washers.
Allow 15°C minimum warm-up time in sub-zero environments.
Lubricate pivot points every 500,000 cycles using MIL-PRF-6085 grease.
Critical note:
Avoid side-loading beyond 200N radial force.
Use speed controller (ASC-02 accessory) when cycle rate exceeds 60 RPM
to prevent gear wear.
| Property | Property Value |
|---|---|
| sku | HRQ50A |
| Side Port | M5×0.8 |
| Front Port | PT1/8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Hydraulic Shock Absorber Cushioning |
| Specification | Bore Size: 50mm |
