Airtac HRQ Rotary Cylinder HRQ70A
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Series Rotary Cylinder HRQ70A Specifications
- Model: HRQ70A (Standard Rotation Type)
- Rotation Angle: 0-190° adjustable (standard 90° or 180° preset)
- Torque Output: 1.47 N·m @0.5MPa (dynamic), 2.94 N·m @0.5MPa (static)
- Operating Pressure: 0.1-0.7 MPa
- Port Size: PT1/4 (G1/4 optional)
- Piston Diameter: Ø70 mm
- Shaft Diameter: Ø12 mm (hardened stainless steel)
- Rotation Speed: 50-300 rpm (lubricated condition)
- Temperature Range: -20℃ to 80℃
- Body Material: Aluminum alloy (anodized finish)
- Seal Material: NBR + Polyurethane (oil & dust resistant)
- Weight: 0.95 kg (excluding accessories)
- Dimensions: 70mm(W) × 70mm(H) × 117mm(L) (excluding shaft protrusion)
- Mounting: Standard ISO 15552 front flange pattern
- Cushioning: Adjustable pneumatic cushion (both ends)
- Protection Class: IP40 (IP67 available with optional cover)
High-precision rotary actuator with dual angular adjustment, featuring wear-resistant chromium-plated bearing surfaces and zero-backlash gear mechanism. The HRQ70A delivers repeat positioning accuracy within ±0.5° and includes integrated magnetic slots for sensor mounting. Requires 5μm filtered air with ISO VG32 turbine oil mist lubrication (0.1-0.3cc/min recommended).
- 90° part flipping in automated assembly lines
- Valve actuation in packaging machinery
- Workpiece indexing in CNC loading systems
- Solar panel tracking mechanisms
- Conveyor diverter gate control
Installation note:
Maintain 0.5-1mm clearance between mechanical stopper and arm during setup.
For vertical mounting, install exhaust mist lubricator to prevent seal drying.
Maximum lateral load: 50N at shaft end.
| Property | Property Value |
|---|---|
| sku | HRQ70A |
| Side Port | M5×0.8 |
| Front Port | PT1/8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Hydraulic Shock Absorber Cushioning |
| Specification | Bore 70 |
