Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X10-10S
The AirTAC Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X10-10S is a genuine double acting, adjustable stroke + cushion standard round-body mini air cylinder with a Ø16mm bore and 10mm stroke, M5×0.8 air ports and a stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service. A variable air cushion at both ends lets you tune end-of-stroke deceleration on site.
- BoreØ16 mm
- Stroke10 mm
- Port sizeM5×0.8
- Acting typeDouble acting, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X10-10S
A stubby 10 mm stroke and a 10 mm trim window make the MACJ16X10-10S a compact positioner for cramped fixtures. It is double-acting with a variable air cushion at both ends, and an external stop screw shortens the extend stroke on site inside the ordered 10 mm window. The body is a stainless round barrel rolled onto aluminium covers, driving a hard-chrome plated carbon-steel rod that shrugs off washdown mist where painted minis corrode. At 0.5 MPa it pushes 100.5 N and pulls 86.4 N.
Run the numbers before sizing: budget about 60 N of actual work at 0.5 MPa, which lifts roughly 5 kg vertically with a 2:1 margin. Pressure spans 0.15-1.0 MPa (22-145 psi) and speed runs 30-800 mm/s. The magnet is built in as standard, so CMSG, DMSG or EMSG switches clip on without a special-order piston.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X10-10S Technical Specifications
| Model | Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X10-10S |
|---|---|
| Series | MACJ mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 10 mm |
| Acting type | Double acting, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC MA-series datasheet. Barrel: stainless-steel tube (round-body, riveted rolling-packed construction); piston rod: carbon steel with 20µm hard-chrome plating; covers: aluminium alloy. Thread options: PT (blank) / G / NPT. Every MA-series cylinder ships with a built-in magnet for CMSG / DMSG / EMSG position sensors.
Theoretical Output Force (Ø16mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 101 N | 86 N |
| 0.7 MPa | 141 N | 121 N |
| Max (@1.0 MPa) | 21 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X10-10S
| MACJ | Standard round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -10 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Built-in magnet for CMSG / DMSG / EMSG sensors (standard on MA series). |
| CA / U / CM | Back-cover type: CA pivot, U flat-end, CM round-end. |
MA-family variants: MA / MAC (double acting ±cushion), MSA / MTA (single acting push / pull), MAD / MACD (double rod ±cushion), MAJ / MACJ (adjustable stroke ±cushion), MAR (cushioned with integrated F/U mount). Mounting accessories: FA flange, LB foot, SDB pivot; plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X10-10S Is Used
Fixture pin ejection
Ejects locating pins from shallow pockets in aluminium drill jigs, where the 10 mm trim window matches exact pin rise without shims.
Small-part kick-off
Taps lip-balm cartons or blister cards sideways off a benchtop conveyor at about 60 N of working force, with cushions softening every tap.
Lab valve actuation
Presses a small dosing valve on a filling rig, where the 5 kg vertical-lift class and stainless barrel suit frequent wipe-downs.
Is the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X10-10S the Right Cylinder?
Bore 16 is the smallest in the MA range; if 100.5 N at 0.5 MPa feels light, step up to bore 20 for 157.0 N. Keep in mind the stop screw fixes the extend end mechanically - it is not a clamp, so the rod will still settle if air is lost. Mount with the FA flange or LB foot, add I or Y rod knuckles if the load pivots, and pick the thread you need: PT as standard, or G and NPT, all on an M5x0.8 port.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) is standard for sensors
- ✓ Back cover (CA/U/CM) & mount (FA/LB/SDB)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion screws and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X10-10S FAQ
At 0.5 MPa it pushes 100.5 N and pulls 86.4 N; at 0.7 MPa that rises to 140.7 N push and 120.9 N pull. The theoretical ceiling is 20.5 kgf at 1.0 MPa. For real work, plan around 60 N at 0.5 MPa - about 5 kg of vertical lift with a 2:1 margin.
The -10 in the code is a 10 mm window: an external stop screw shortens the extend stroke on site within that range. It is a positioning end stop, not a mid-stroke brake, so the rod can still drift if supply pressure drops. Twin variable air cushions at each end absorb the remaining shock.
