Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-100S
The AirTAC Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-100S is a genuine double acting, adjustable stroke + cushion standard round-body mini air cylinder with a Ø16mm bore and 100mm stroke, M5×0.8 air ports and a stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service. A variable air cushion at both ends lets you tune end-of-stroke deceleration on site.
- BoreØ16 mm
- Stroke100 mm
- Port sizeM5×0.8
- Acting typeDouble acting, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-100S
The MACJ16X100-100S carries a trim window as long as its own travel: the -100 code means the extend stroke can be set anywhere within the full 100 mm ordered travel using an on-site stop screw. It is double-acting with variable air cushions at both ends, built as a round stainless barrel rolled onto aluminium covers, driving a hard-chrome plated 6 mm rod through damp or washed-down corners. Output at 0.5 MPa: 100.5 N push, 86.4 N pull.
Sizing math: count on roughly 60 N of usable force at 0.5 MPa, enough to lift near 5 kg vertically with a 2:1 margin. Supply pressure spans 0.15-1.0 MPa (22-145 psi) and speed reaches 800 mm/s. A magnet is factory-fitted, so CMSG, DMSG and EMSG switches drop straight onto the barrel.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-100S Technical Specifications
| Model | Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-100S |
|---|---|
| Series | MACJ mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 100 mm |
| Acting type | Double acting, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC MA-series datasheet. Barrel: stainless-steel tube (round-body, riveted rolling-packed construction); piston rod: carbon steel with 20µm hard-chrome plating; covers: aluminium alloy. Thread options: PT (blank) / G / NPT. Every MA-series cylinder ships with a built-in magnet for CMSG / DMSG / EMSG position sensors.
Theoretical Output Force (Ø16mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 101 N | 86 N |
| 0.7 MPa | 141 N | 121 N |
| Max (@1.0 MPa) | 21 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-100S
| MACJ | Standard round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -100 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Built-in magnet for CMSG / DMSG / EMSG sensors (standard on MA series). |
| CA / U / CM | Back-cover type: CA pivot, U flat-end, CM round-end. |
MA-family variants: MA / MAC (double acting ±cushion), MSA / MTA (single acting push / pull), MAD / MACD (double rod ±cushion), MAJ / MACJ (adjustable stroke ±cushion), MAR (cushioned with integrated F/U mount). Mounting accessories: FA flange, LB foot, SDB pivot; plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-100S Is Used
Carton flap tuck
Tucks flaps on cosmetic cartons along a 100 mm reach, trimmed per SKU on the line without swapping the cylinder.
Height-set stop gate
Positions a product stop gate on a bottle filling line; the window lets operators re-height it for each container batch.
Switch-indexed probe
Pairs with CMSG switches to index a 100 mm inspection probe stroke on an electronics test bench.
Is the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-100S the Right Cylinder?
Weigh it against the fixed-stroke MAC16X100 with cushion: if you never need to retune stroke, the fixed version does the same push at a lower cost, while this one adapts on the machine. Need more muscle? Bore 20 delivers 157.0 N at 0.5 MPa in the same family. The adjuster holds the extend end stop only - on air loss the piston drifts, so add a check or lock valve if the load must hang. With a 6 mm rod over 100 mm of travel, keep side loads off the rod and guide the payload externally. FA flange and LB foot mounts, I and Y knuckles, and an M5x0.8 port (the smallest in the range) complete the order.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) is standard for sensors
- ✓ Back cover (CA/U/CM) & mount (FA/LB/SDB)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion screws and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-100S FAQ
Design values: 100.5 N push and 86.4 N pull at 0.5 MPa; 140.7 N push and 120.9 N pull at 0.7 MPa; 20.5 kgf theoretical maximum at 1.0 MPa. Derate to about 60 N of working force for a stable long-term margin.
The rolled stainless tube with aluminium end caps shrugs off washdown mist and mild corrosion that blister painted mini cylinders, while the hard-chrome plated 6 mm rod keeps the seals happy over long duty. Variable air cushions at each end let the 100 mm travel land gently even near the top of the 30-800 mm/s range.
