Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-20S
The AirTAC Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-20S is a genuine double acting, adjustable stroke + cushion standard round-body mini air cylinder with a Ø16mm bore and 100mm stroke, M5×0.8 air ports and a stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service. A variable air cushion at both ends lets you tune end-of-stroke deceleration on site.
- BoreØ16 mm
- Stroke100 mm
- Port sizeM5×0.8
- Acting typeDouble acting, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-20S
Double acting, cushioned at each end, and tunable: the MACJ16X100-20S lets a stop screw pull the extend stroke back by as much as 20 mm from its 100 mm ordered travel. The actuator wraps a stainless steel tube in a rolled, riveted body with aluminium covers, swinging a hard-chrome carbon-steel rod that copes with washdown corners and outdoor mist. Rated 100.5 N push and 86.4 N pull at 0.5 MPa.
For sizing, treat about 60 N as the honest working force at 0.5 MPa - that lifts close to 5 kg vertically once you halve the raw 10 kg equivalent for margin. It runs on 0.15-1.0 MPa (22-145 psi) air filtered to 40 um, at 30-800 mm/s. The magnet is standard fitment, so CMSG / DMSG / EMSG sensors attach with no option codes.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-20S Technical Specifications
| Model | Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-20S |
|---|---|
| Series | MACJ mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 100 mm |
| Acting type | Double acting, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC MA-series datasheet. Barrel: stainless-steel tube (round-body, riveted rolling-packed construction); piston rod: carbon steel with 20µm hard-chrome plating; covers: aluminium alloy. Thread options: PT (blank) / G / NPT. Every MA-series cylinder ships with a built-in magnet for CMSG / DMSG / EMSG position sensors.
Theoretical Output Force (Ø16mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 101 N | 86 N |
| 0.7 MPa | 141 N | 121 N |
| Max (@1.0 MPa) | 21 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-20S
| MACJ | Standard round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -20 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Built-in magnet for CMSG / DMSG / EMSG sensors (standard on MA series). |
| CA / U / CM | Back-cover type: CA pivot, U flat-end, CM round-end. |
MA-family variants: MA / MAC (double acting ±cushion), MSA / MTA (single acting push / pull), MAD / MACD (double rod ±cushion), MAJ / MACJ (adjustable stroke ±cushion), MAR (cushioned with integrated F/U mount). Mounting accessories: FA flange, LB foot, SDB pivot; plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-20S Is Used
Vertical indexing pin
Drops a locating pin into fixture bushings under an SMT stencil cart, trimmed per tray height within the 20 mm window.
Tote latch release
Pops latch hooks on dairy totes at a washdown palletiser, where the stainless barrel handles caustic rinse cycles.
Glue-dab station
Dabs contact adhesive dots on shoe-sole blanks with a trimmable probe stroke, cushions preventing splatter at speed.
Is the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-20S the Right Cylinder?
Consider the MACD16X100 double-rod version if you ever need a rod at both ends - this adjustable model has no double-rod variant. If 100.5 N at 0.5 MPa is marginal for your load, bore 20 offers 157.0 N in the same family. The screw trims stroke but does not lock it: with air lost, the piston can be back-driven, so fit an external check for suspended loads. Long 100 mm strokes on a 6 mm rod dislike side loads - carry the load on an external guide and keep the cylinder in pure push-pull. FA flange or LB foot, I and Y knuckles, and PT / G / NPT threads (M5x0.8 on this bore) round out the order.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) is standard for sensors
- ✓ Back cover (CA/U/CM) & mount (FA/LB/SDB)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion screws and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-20S FAQ
Full figures: 100.5 N push and 86.4 N pull at 0.5 MPa; 140.7 N push and 120.9 N pull at 0.7 MPa; and a theoretical maximum of 20.5 kgf at 1.0 MPa. A practical target is about 60 N of working force at 0.5 MPa, near 5 kg of vertical lift.
Each end carries a variable air cushion: turn the adjustment screw to meter the exhaust and the 100 mm stroke decelerates progressively instead of hammering the covers. That lets you push toward the top of the 30-800 mm/s band with heavier jigs and still get a soft landing, with no external shock absorbers needed on light loads.
