Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-40S
The AirTAC Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-40S is a genuine double acting, adjustable stroke + cushion standard round-body mini air cylinder with a Ø16mm bore and 100mm stroke, M5×0.8 air ports and a stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service. A variable air cushion at both ends lets you tune end-of-stroke deceleration on site.
- BoreØ16 mm
- Stroke100 mm
- Port sizeM5×0.8
- Acting typeDouble acting, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-40S
A 16 mm bore with a 100 mm travel and a 40 mm on-site trim window - the MACJ16X100-40S shortens its extend stroke wherever the job lands, backed by a variable air cushion at each end. At 0.5 MPa you get 100.5 N push and 86.4 N pull, climbing to 140.7 N push at 0.7 MPa. Working range 0.15-1.0 MPa (22-145 psi), speed 30-800 mm/s.
Because the barrel is stainless and the 6 mm rod is hard-chrome plated carbon steel, this round-body mini takes humid cells, coolant mist and outdoor cabinets without flaking paint. Every unit ships with its magnet fitted, so DMSG or CMSG switches clip straight on. Practical number: budget about 60 N for actual work at 0.5 MPa - around 5 kg of vertical lift at a 2:1 margin.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-40S Technical Specifications
| Model | Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-40S |
|---|---|
| Series | MACJ mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 100 mm |
| Acting type | Double acting, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC MA-series datasheet. Barrel: stainless-steel tube (round-body, riveted rolling-packed construction); piston rod: carbon steel with 20µm hard-chrome plating; covers: aluminium alloy. Thread options: PT (blank) / G / NPT. Every MA-series cylinder ships with a built-in magnet for CMSG / DMSG / EMSG position sensors.
Theoretical Output Force (Ø16mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 101 N | 86 N |
| 0.7 MPa | 141 N | 121 N |
| Max (@1.0 MPa) | 21 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-40S
| MACJ | Standard round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -40 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Built-in magnet for CMSG / DMSG / EMSG sensors (standard on MA series). |
| CA / U / CM | Back-cover type: CA pivot, U flat-end, CM round-end. |
MA-family variants: MA / MAC (double acting ±cushion), MSA / MTA (single acting push / pull), MAD / MACD (double rod ±cushion), MAJ / MACJ (adjustable stroke ±cushion), MAR (cushioned with integrated F/U mount). Mounting accessories: FA flange, LB foot, SDB pivot; plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-40S Is Used
Carton push-off
Nudges a folded carton off a filling station table into a collection chute, with the extend stroke trimmed across 40 mm to match the layout.
Fixture clamp
Clamps a PCB or small housing into a drilling jig; the stop screw lets technicians re-set clamp travel without new hardware.
Sample arm
Dips and retracts a small sampling probe into a liquid line at a bottling lab, with an EMSG switch confirming each stroke end.
Is the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-40S the Right Cylinder?
Compare before you buy: the next size up, bore 20, pushes 157 N at 0.5 MPa, and bore 25 reaches 245.3 N - but for tight envelopes, nothing beats the 16 mm footprint. Note that the mechanical adjuster sets the end of travel; it will not hold a load against gravity when supply drops. Choose FA flange or LB foot mounting, I or Y knuckles for pivoting links; with a 6 mm rod over 100 mm of stroke, minimize side load or guide the load externally. The built-in magnet makes position sensing a plug-on job.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) is standard for sensors
- ✓ Back cover (CA/U/CM) & mount (FA/LB/SDB)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion screws and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X100-40S FAQ
Use 100.5 N push and 86.4 N pull at 0.5 MPa, or 140.7 N push at 0.7 MPa; the theoretical peak is 20.5 kgf at 1.0 MPa. It runs 30-800 mm/s on 0.15-1.0 MPa (22-145 psi) air, with the extend stroke trimmed anywhere in the 40 mm window.
Each end carries a variable cushion, so end-of-stroke shock is dialled out by the port-side restrictor rather than by slowing the whole cycle - useful when a 100 N class cylinder must cycle fast or carry a heavier load to a soft stop.
