Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X125-40S
The AirTAC Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X125-40S is a genuine double acting, adjustable stroke + cushion standard round-body mini air cylinder with a Ø16mm bore and 125mm stroke, M5×0.8 air ports and a stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service. A variable air cushion at both ends lets you tune end-of-stroke deceleration on site.
- BoreØ16 mm
- Stroke125 mm
- Port sizeM5×0.8
- Acting typeDouble acting, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X125-40S
With a 40 mm adjustable window, the MACJ16X125-40S lets you shorten the extend stroke on site with a stop screw, so one cylinder can be dialled into several fixture positions. It is double-acting with a variable air cushion at both ends, running 0.15-1.0 MPa (22-145 psi) and 30-800 mm/s.
At 0.5 MPa the 16 mm bore pushes 100.5 N and pulls 86.4 N, so plan continuous work around 60 N. The stainless round barrel and hard-chrome plated rod shrug off washdown and damp air, a real edge over painted mini cylinders, and the riveted aluminium covers keep the rolled body sealed. A magnet is built in as standard, so CMSG, DMSG or EMSG switches clip on without a special piston.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X125-40S Technical Specifications
| Model | Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X125-40S |
|---|---|
| Series | MACJ mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 125 mm |
| Acting type | Double acting, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC MA-series datasheet. Barrel: stainless-steel tube (round-body, riveted rolling-packed construction); piston rod: carbon steel with 20µm hard-chrome plating; covers: aluminium alloy. Thread options: PT (blank) / G / NPT. Every MA-series cylinder ships with a built-in magnet for CMSG / DMSG / EMSG position sensors.
Theoretical Output Force (Ø16mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 101 N | 86 N |
| 0.7 MPa | 141 N | 121 N |
| Max (@1.0 MPa) | 21 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X125-40S
| MACJ | Standard round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×125 | Stroke length in mm. |
| -40 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Built-in magnet for CMSG / DMSG / EMSG sensors (standard on MA series). |
| CA / U / CM | Back-cover type: CA pivot, U flat-end, CM round-end. |
MA-family variants: MA / MAC (double acting ±cushion), MSA / MTA (single acting push / pull), MAD / MACD (double rod ±cushion), MAJ / MACJ (adjustable stroke ±cushion), MAR (cushioned with integrated F/U mount). Mounting accessories: FA flange, LB foot, SDB pivot; plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X125-40S Is Used
Gate push-off on food lines
Washdown-safe stainless body plus 60 N of usable push suits sliding small trays off a conveyor at up to 800 mm/s.
Lid-tuck on carton packers
Trim the extend stroke anywhere in the 40 mm window to seat lids on mixed carton sizes without re-plumbing the machine.
End-of-stroke confirmation
The standard magnet drives CMSG or DMSG switches, so the PLC sees a confirmed 125 mm reach on every cycle.
Is the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X125-40S the Right Cylinder?
The 16 mm bore is the smallest in the MA series; if 100.5 N at 0.5 MPa falls short, step up to bore 20 (157 N) or bore 25 (245.3 N). The adjuster is a mechanical end stop for the extend stroke only - it will not hold a load if air is lost, so fit a valving solution for that job. Mount with an FA flange or LB foot, add I or Y rod knuckles where the load pivots, and keep side loads off the 6 mm rod across the 125 mm travel.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) is standard for sensors
- ✓ Back cover (CA/U/CM) & mount (FA/LB/SDB)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion screws and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X125-40S FAQ
At 0.5 MPa this cylinder pushes 100.5 N and pulls 86.4 N; at 0.7 MPa that rises to 140.7 N push and 120.9 N pull. Theoretical peak force is 20.5 kgf at 1.0 MPa. Port size is M5x0.8 and the rod thread is M6x1.0.
The stop screw shortens the extend stroke anywhere within a 40 mm window; it cannot extend beyond the ordered 125 mm stroke. It is an end stop, not a mid-stroke lock, and the variable cushion still absorbs shock at both ends.
