Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-10S
The AirTAC Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-10S is a genuine double acting, adjustable stroke + cushion standard round-body mini air cylinder with a Ø16mm bore and 150mm stroke, M5×0.8 air ports and a stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service. A variable air cushion at both ends lets you tune end-of-stroke deceleration on site.
- BoreØ16 mm
- Stroke150 mm
- Port sizeM5×0.8
- Acting typeDouble acting, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-10S
A fine 10 mm trim window on a 150 mm extend stroke makes this 16 mm MACJ the pick when final positioning must be nudged on the machine rather than re-engineered. It is double-acting with variable cushioning at both ends, rated 0.15-1.0 MPa (22-145 psi) and 30-800 mm/s. At 0.5 MPa expect 100.5 N of push, about 60 N of dependable working force once you keep a sensible margin, and 140.7 N at 0.7 MPa.
The rolling-packed body pairs a stainless barrel with a hard-chrome carbon-steel rod, so light corrosion and washdown are non-issues where painted minis would flake. The magnet comes standard, feeding CMSG, DMSG or EMSG switches out of the box.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-10S Technical Specifications
| Model | Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-10S |
|---|---|
| Series | MACJ mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 150 mm |
| Acting type | Double acting, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC MA-series datasheet. Barrel: stainless-steel tube (round-body, riveted rolling-packed construction); piston rod: carbon steel with 20µm hard-chrome plating; covers: aluminium alloy. Thread options: PT (blank) / G / NPT. Every MA-series cylinder ships with a built-in magnet for CMSG / DMSG / EMSG position sensors.
Theoretical Output Force (Ø16mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 101 N | 86 N |
| 0.7 MPa | 141 N | 121 N |
| Max (@1.0 MPa) | 21 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-10S
| MACJ | Standard round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×150 | Stroke length in mm. |
| -10 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Built-in magnet for CMSG / DMSG / EMSG sensors (standard on MA series). |
| CA / U / CM | Back-cover type: CA pivot, U flat-end, CM round-end. |
MA-family variants: MA / MAC (double acting ±cushion), MSA / MTA (single acting push / pull), MAD / MACD (double rod ±cushion), MAJ / MACJ (adjustable stroke ±cushion), MAR (cushioned with integrated F/U mount). Mounting accessories: FA flange, LB foot, SDB pivot; plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-10S Is Used
Connector seating press
Seating small connectors into housings on an electronics assembly cell, using the 10 mm window to dial in exact seating depth after tooling swaps.
Date coder stroke
Driving a lightweight print head on a packaging date coder, where the stainless rod resists ink and cleaner residue and the trim screw squares up the print gap.
Microplate lift
Raising microplates about 5 kg-equivalent in a screening station, with the 60 N working margin keeping lifts smooth at 0.5 MPa.
Is the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-10S the Right Cylinder?
The 16 mm bore is the smallest in the MA range, so if 100.5 N at 0.5 MPa is still surplus, trim the supply pressure down instead of hunting for a smaller cylinder. The next size up, 20 mm, delivers 157.0 N push at 0.5 MPa. Treat the -10 adjuster as a mechanical extend limit only; it cannot hold position when air is lost, so park loads against a hard stop or a valved circuit. FA flange and LB foot mounts, plus I and Y knuckles, cover the fixing options.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) is standard for sensors
- ✓ Back cover (CA/U/CM) & mount (FA/LB/SDB)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion screws and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-10S FAQ
Push at 0.5 MPa is 100.5 N and pull is 86.4 N; at 0.7 MPa push is 140.7 N and pull 120.9 N. The theoretical maximum is 20.5 kgf at 1.0 MPa. It runs on 0.15-1.0 MPa (22-145 psi) at 30-800 mm/s, double-acting with a 10 mm adjustable extend window.
Yes. The round barrel is high-precision stainless steel and the rod is carbon steel with a 20 um hard-chrome plating, so splash zones, food washdown and outdoor cells will not rust it the way painted or plain aluminium minis corrode. The riveted aluminium covers keep the seal integrity intact over years of cycling.
