Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-20S
The AirTAC Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-20S is a genuine double acting, adjustable stroke + cushion standard round-body mini air cylinder with a Ø16mm bore and 150mm stroke, M5×0.8 air ports and a stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service. A variable air cushion at both ends lets you tune end-of-stroke deceleration on site.
- BoreØ16 mm
- Stroke150 mm
- Port sizeM5×0.8
- Acting typeDouble acting, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-20S
Cushioned, trimmable and compact, this MACJ pairs a 150 mm extend stroke with a 20 mm on-site trim window and a variable air cushion at each end, so end-of-travel shock stays low even near the 800 mm/s speed ceiling. Double-acting on 0.15-1.0 MPa (22-145 psi), the 16 mm bore produces 100.5 N push and 86.4 N pull at 0.5 MPa, enough to lift about 5 kg vertically with a 2:1 margin.
The rolling-packed body combines a stainless barrel, a hard-chrome plated 6 mm rod and aluminium covers, standing up to splashes that would rust painted minis. Its standard-fit magnet drives CMSG, DMSG or EMSG switches for repeatable end-position detection.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-20S Technical Specifications
| Model | Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-20S |
|---|---|
| Series | MACJ mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 150 mm |
| Acting type | Double acting, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC MA-series datasheet. Barrel: stainless-steel tube (round-body, riveted rolling-packed construction); piston rod: carbon steel with 20µm hard-chrome plating; covers: aluminium alloy. Thread options: PT (blank) / G / NPT. Every MA-series cylinder ships with a built-in magnet for CMSG / DMSG / EMSG position sensors.
Theoretical Output Force (Ø16mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 101 N | 86 N |
| 0.7 MPa | 141 N | 121 N |
| Max (@1.0 MPa) | 21 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-20S
| MACJ | Standard round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×150 | Stroke length in mm. |
| -20 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Built-in magnet for CMSG / DMSG / EMSG sensors (standard on MA series). |
| CA / U / CM | Back-cover type: CA pivot, U flat-end, CM round-end. |
MA-family variants: MA / MAC (double acting ±cushion), MSA / MTA (single acting push / pull), MAD / MACD (double rod ±cushion), MAJ / MACJ (adjustable stroke ±cushion), MAR (cushioned with integrated F/U mount). Mounting accessories: FA flange, LB foot, SDB pivot; plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-20S Is Used
Guard door latch actuator
A light interlock plunger on a machine guard, with the standard magnet and an EMSG switch proving the door is positively opened at each cycle.
Sample carousel indexing
Advancing a small rotary sample carousel in an analytical instrument, where the 20 mm trim window aligns each station after refits.
Checkweigher reject arm
Tipping light underweight packs off a checkweigher belt with 100.5 N at 0.5 MPa, the dual cushions damping the kick at speed.
Is the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-20S the Right Cylinder?
If 100.5 N push at 0.5 MPa falls short, the 20 mm MA bore reaches 157.0 N and the 25 mm bore 245.3 N at the same pressure, so size by measured load rather than guesswork. At 150 mm of stroke, keep side loads off the 6 mm rod with external guides or an I or Y knuckle. Do not count on the stop screw to park a load: it sets the extend limit only, and the rod coasts if pressure vanishes. FA flange and LB foot fixings, PT threads standard with G and NPT variants.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) is standard for sensors
- ✓ Back cover (CA/U/CM) & mount (FA/LB/SDB)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion screws and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-20S FAQ
Push 100.5 N and pull 86.4 N at 0.5 MPa; push 140.7 N and pull 120.9 N at 0.7 MPa; theoretical maximum 20.5 kgf at 1.0 MPa. Bore 16 mm, stroke 150 mm with a 20 mm adjustable extend window, double-acting, variable air cushion both ends, 0.15-1.0 MPa (22-145 psi), 30-800 mm/s.
No. Every MA-series cylinder, including this one, ships with the magnet built in as standard. CMSG, DMSG and EMSG reed or hall-effect switches mount directly on the stainless barrel, giving you end-of-stroke or intermediate position signals without any custom piston or price bump.
