Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-40S
The AirTAC Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-40S is a genuine double acting, adjustable stroke + cushion standard round-body mini air cylinder with a Ø16mm bore and 150mm stroke, M5×0.8 air ports and a stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service. A variable air cushion at both ends lets you tune end-of-stroke deceleration on site.
- BoreØ16 mm
- Stroke150 mm
- Port sizeM5×0.8
- Acting typeDouble acting, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-40S
Over a 40 mm window the extend stroke of this MACJ16X150-40S can be shortened at the machine without ordering a new cylinder - the screw stop sets where the 150 mm travel ends. It is double-acting with a variable cushion at each end and a 30-800 mm/s speed band, running on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi). The 16 mm bore delivers 100.5 N forward and 86.4 N back at 0.5 MPa.
Build quality is where this mini earns its keep: a stainless round tube riveted to aluminium covers, with a hard-chrome plated rod that keeps sliding wear low in damp or dusty shops. Halve the rated push for margin and you can lift about 5 kg vertically - enough for small chucks, caps or sensor fixtures. Every unit ships magnet-on, ready for EMSG reed or DMSG Hall-effect switches.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-40S Technical Specifications
| Model | Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-40S |
|---|---|
| Series | MACJ mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 150 mm |
| Acting type | Double acting, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC MA-series datasheet. Barrel: stainless-steel tube (round-body, riveted rolling-packed construction); piston rod: carbon steel with 20µm hard-chrome plating; covers: aluminium alloy. Thread options: PT (blank) / G / NPT. Every MA-series cylinder ships with a built-in magnet for CMSG / DMSG / EMSG position sensors.
Theoretical Output Force (Ø16mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 101 N | 86 N |
| 0.7 MPa | 141 N | 121 N |
| Max (@1.0 MPa) | 21 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-40S
| MACJ | Standard round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×150 | Stroke length in mm. |
| -40 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Built-in magnet for CMSG / DMSG / EMSG sensors (standard on MA series). |
| CA / U / CM | Back-cover type: CA pivot, U flat-end, CM round-end. |
MA-family variants: MA / MAC (double acting ±cushion), MSA / MTA (single acting push / pull), MAD / MACD (double rod ±cushion), MAJ / MACJ (adjustable stroke ±cushion), MAR (cushioned with integrated F/U mount). Mounting accessories: FA flange, LB foot, SDB pivot; plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-40S Is Used
Carton tab folder
Folds small carton tabs on a cosmetic box line; the 40 mm trim window matches different carton depths and the two-end cushion stops tab hammering at line speed.
Belt-line reject gate
Swings a light reject gate on a snack-food conveyor; the stainless barrel handles routine hose-down and the 86.4 N pull returns the gate promptly between products.
Jig clamp for TIG fixtures
Clamps thin brackets in a TIG weld jig where 60 N of practical force is ample; the hard-chrome rod resists staining between wipe-downs in coolant-misted shops.
Is the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-40S the Right Cylinder?
If 100.5 N at 0.5 MPa is not enough for the job, the next MA size up, the 20 mm bore, reaches 157.0 N, and the 25 mm bore 245.3 N - both at the same supply. Proof pressure is 1.5 MPa (215 psi), so brief spikes are handled. Porting is M5x0.8 on this bore size; FA flange and LB foot plates, plus I and Y knuckles, cover most fixturing.
The stop screw is a position setter, not a holding brake: without air the rod is free to move, so clamp loads elsewhere where hold matters. On a 150 mm stroke with a 6 mm rod, keep thrust in line with the rod axis and support side loads externally; the built-in magnet pairs with CMSG/DMSG/EMSG switches for end-of-travel confirmation.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) is standard for sensors
- ✓ Back cover (CA/U/CM) & mount (FA/LB/SDB)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion screws and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X150-40S FAQ
Full set at the 16 mm bore: push 100.5 N and pull 86.4 N at 0.5 MPa; push 140.7 N and pull 120.9 N at 0.7 MPa; 20.5 kgf theoretical maximum at 1.0 MPa. Design around roughly 60 N of usable push at the lower pressure for long seal life.
The barrel is stainless steel with rolled aluminium covers, unlike painted-steel minis that chip in wet areas. The 6 mm rod is hard-chrome plated for wear, the magnet is included as standard for CMSG/DMSG/EMSG sensing, and both ends have a variable cushion you can tune with a screwdriver.
