Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X160-10S
2. Features custom-profiled bidirectional piston seals with compact dimensions and integrated oil reservoir design;
3. Integrated shock-absorbing pads on both end caps minimize directional change impact;
4. Multiple rear cap configurations for enhanced mounting flexibility;
5. Robust riveted composite enclosure structure securely joins stainless steel barrel with end caps;
6. Precision-engineered stainless steel tubing ensures high mechanical strength and corrosion resistance;
7. Comprehensive selection of cylinder sizes and mounting accessories available;
8. Full-range magnetic piston configuration across series.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MACJ
AirTAC MACJ16X160-10S Stainless Steel Mini Adjustable Cylinder Specifications
- Model: MACJ16X160-10S
- Type: Single-acting spring return (adjustable stroke)
- Bore size: 16mm
- Stroke: 160mm (adjustable via built-in stroke limiter)
- Operating pressure: 0.1–1.0 MPa
- Medium: Clean dry air (non-lubricated operation supported)
- Cushioning: Rubber buffer + adjustable end lock
- Mounting type: Basic (axial mounting taps on both ends)
- Rod thread: M5×0.8 external thread
- Material: Stainless steel body (SUS304), nitrile rubber seals
- Temperature range: -20℃ to 150℃
- Weight: 0.68kg (excluding accessories)
- Dimensions: 220mm(L) × 40mm(W) × 40mm(H) (max extended length)
- Repeat accuracy: ±0.5mm
- IP rating: IP40 (standard), IP67 optional with rod cover
- Sensor compatibility: Built-in magnet for magnetic reed switches
Ultra-compact stainless steel cylinder engineered for precision positioning in corrosive or washdown environments. Features a unique dual-adjustment system allowing both mechanical stroke limitation (via locknut) and fine-tuning through the threaded rod. The full stainless construction prevents rust in high-humidity applications while maintaining sterilization compatibility.
- Pharmaceutical tablet press machines
- Food packaging line gripper positioning
- Semiconductor wafer handling robots
- Laboratory liquid dispensing systems
- Marine equipment actuators
Installation note:
For optimal performance, align within 0.5° angular misalignment maximum.
Use PTFE-based lubricant if operating below -10℃. Regular cleaning recommended
when exposed to salt spray or chemical vapors.
| Property | Property Value |
|---|---|
| sku | MACJ16X160-10S |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 160mm |
