Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X160-20S
2. Features custom-profiled bidirectional piston seals with compact dimensions and integrated oil reservoir design;
3. Integrated shock-absorbing pads on both end caps minimize directional change impact;
4. Multiple rear cap configurations for enhanced mounting flexibility;
5. Robust riveted composite enclosure structure securely joins stainless steel barrel with end caps;
6. Precision-engineered stainless steel tubing ensures high mechanical strength and corrosion resistance;
7. Comprehensive selection of cylinder sizes and mounting accessories available;
8. Full-range magnetic piston configuration across series.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MACJ
AirTAC MACJ16X160-20S Stainless Steel Mini Adjustable Cylinder Specifications
- Model: MACJ16X160-20S
- Bore size: 16mm
- Stroke: 160mm
- Adjustment type: External adjustable cushioning (20mm adjustment range)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -10℃ to 70℃
- Port size: M5×0.8 (dual ports)
- Cushion type: Rubber buffer + adjustable needle valve
- Body material: Stainless steel (SUS304)
- Rod material: Stainless steel (SUS304)
- End cover material: Anodized aluminum alloy
- Piston seal: NBR rubber
- Weight: 480g ±2%
- Dimensions:
- Extended length: 250mm
- Retracted length: 90mm
- Body diameter: 22mm
- Mounting bracket width: 34mm
- ISO standard: 6432 (compact series)
- Corrosion resistance: IP67 rating
Precision mini cylinder with stainless steel construction for harsh environments, featuring dual-side adjustable cushioning for smooth stroke termination. The compact design integrates an anti-rotation guide slot (4mm width) and wear-resistant piston guides. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Semiconductor wafer handling robots
- Pharmaceutical capsule filling machines
- Food packaging line actuators
- Laboratory analytical instrument positioning
- Cleanroom automation systems
Installation note:
Maintain 0.5mm alignment tolerance during mounting. For vertical installations,
use locking nut (M10×1.25) to secure adjustment screws. Lubricate every 50,000 cycles
with AirTAC P-1S lithium soap grease. Maximum side load: 15N.
| Property | Property Value |
|---|---|
| sku | MACJ16X160-20S |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 160mm |
