Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X160-30S
$50.93
Regular price
$58.43
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MACJ16X160-30S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Manufactured in compliance with proprietary corporate standards;
2. Features custom-profiled bidirectional piston seals with compact dimensions and integrated oil reservoir design;
3. Integrated shock-absorbing pads on both end caps minimize directional change impact;
4. Multiple rear cap configurations for enhanced mounting flexibility;
5. Robust riveted composite enclosure structure securely joins stainless steel barrel with end caps;
6. Precision-engineered stainless steel tubing ensures high mechanical strength and corrosion resistance;
7. Comprehensive selection of cylinder sizes and mounting accessories available;
8. Full-range magnetic piston configuration across series.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MACJ
Installation Guidelines:
Use thread locker on mounting screws (Torque ≤3.5N·m). Maintain 0.5-1mm clearance between adjustment screws and stoppers during initial installation. Lubricate with ISO VG32 hydraulic oil if used in low-speed applications (<50mm/s).
Avoid lateral loading >15N. For vertical mounting, use external guides if payload exceeds 2kg. Requires 5μm filtered air supply with oil mist (ISO 8573-1:2010 Class 4).
2. Features custom-profiled bidirectional piston seals with compact dimensions and integrated oil reservoir design;
3. Integrated shock-absorbing pads on both end caps minimize directional change impact;
4. Multiple rear cap configurations for enhanced mounting flexibility;
5. Robust riveted composite enclosure structure securely joins stainless steel barrel with end caps;
6. Precision-engineered stainless steel tubing ensures high mechanical strength and corrosion resistance;
7. Comprehensive selection of cylinder sizes and mounting accessories available;
8. Full-range magnetic piston configuration across series.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MACJ
AirTAC MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X160-30S Specifications
- Model: MACJ16X160-30S
- Series: MACJ Mini Adjustable Stroke Cylinder
- Bore Size: 16mm
- Stroke: 160mm (Adjustable)
- Material: Stainless Steel (SUS304 Barrel & Piston Rod)
- Seal Material: NBR + PU Hybrid Seals
- Operating Pressure: 0.05–0.8 MPa
- Operating Temperature: -20℃ to 80℃
- Cushioning: Rubber Cushioning (Adjustable at Both Ends)
- Mounting Style: Rear Thread Mounting (M12x1.25)
- Port Size: M5x0.8 Thread (Standard)
- Weight: 0.82kg (Excluding Accessories)
- Dimensions:
- Total Length (Extended): 240mm
- Body Diameter: 40mm
- Rod End Thread: M8x1.25
- Stroke Adjustment Range: ±2mm
- Protection Rating: IP67 (Dust/Water Resistant)
- ISO Standard: Compliant with ISO 6432 Mini Cylinder Specifications
Ultra-compact stainless steel cylinder with precision stroke adjustment mechanism, featuring corrosion-resistant construction for harsh environments. The double-cushion design minimizes end-impact noise (≤65dB) while maintaining positioning accuracy (±0.5mm repeatability). Includes anti-rotation guide slots for stable linear motion.
Typical Applications:
- Cleanroom automation in semiconductor manufacturing
- Food processing machinery (FDA-compliant lubrication)
- Medical device positioning systems
- Marine equipment actuators
- High-cycle laboratory automation (Up to 1,200 cpm)
Installation Guidelines:
Use thread locker on mounting screws (Torque ≤3.5N·m). Maintain 0.5-1mm clearance between adjustment screws and stoppers during initial installation. Lubricate with ISO VG32 hydraulic oil if used in low-speed applications (<50mm/s).
Avoid lateral loading >15N. For vertical mounting, use external guides if payload exceeds 2kg. Requires 5μm filtered air supply with oil mist (ISO 8573-1:2010 Class 4).
| Property | Property Value |
|---|---|
| sku | MACJ16X160-30S |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 160mm |
