Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X160-40S
The AirTAC Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X160-40S is a genuine double acting, adjustable stroke + cushion standard round-body mini air cylinder with a Ø16mm bore and 160mm stroke, M5×0.8 air ports and a stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service. A variable air cushion at both ends lets you tune end-of-stroke deceleration on site.
- BoreØ16 mm
- Stroke160 mm
- Port sizeM5×0.8
- Acting typeDouble acting, adjustable stroke + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X160-40S
Within the 16 mm MA range, the MACJ16X160-40S is a double-acting round-body mini cylinder with an adjustable extend stroke. An external stop screw shortens the stroke anywhere inside the ordered 40 mm window, and a variable air cushion at both ends soaks up end-of-travel shock. At 0.5 MPa it delivers 100.5 N of push and 86.4 N of pull.
The riveted stainless barrel and hard-chrome plated rod handle damp, washdown-prone corners far better than painted minis. The magnet is built in as standard, so CMSG, DMSG or EMSG switches clip straight on without a special-order piston. In practice, plan on roughly 60 N of real working force at 0.5 MPa, or about 5 kg of vertical lift with a 2:1 margin.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X160-40S Technical Specifications
| Model | Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X160-40S |
|---|---|
| Series | MACJ mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 160 mm |
| Acting type | Double acting, adjustable stroke + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC MA-series datasheet. Barrel: stainless-steel tube (round-body, riveted rolling-packed construction); piston rod: carbon steel with 20µm hard-chrome plating; covers: aluminium alloy. Thread options: PT (blank) / G / NPT. Every MA-series cylinder ships with a built-in magnet for CMSG / DMSG / EMSG position sensors.
Theoretical Output Force (Ø16mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 101 N | 86 N |
| 0.7 MPa | 141 N | 121 N |
| Max (@1.0 MPa) | 21 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X160-40S
| MACJ | Standard round-body mini cylinder (adjustable-stroke, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×160 | Stroke length in mm. |
| -40 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Built-in magnet for CMSG / DMSG / EMSG sensors (standard on MA series). |
| CA / U / CM | Back-cover type: CA pivot, U flat-end, CM round-end. |
MA-family variants: MA / MAC (double acting ±cushion), MSA / MTA (single acting push / pull), MAD / MACD (double rod ±cushion), MAJ / MACJ (adjustable stroke ±cushion), MAR (cushioned with integrated F/U mount). Mounting accessories: FA flange, LB foot, SDB pivot; plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X160-40S Is Used
Bottling-line reject pusher
Knocks a mis-capped bottle off a narrow conveyor lane at 100.5 N, with the 40 mm trim letting maintenance match the lane without re-piping air lines.
Fixture part ejection
Ejects a finished bushing from a small drilling fixture; the trim window absorbs fixture rework and the dual cushions stop the 6 mm rod slamming home.
Vial indexing on a lab bench
Steps sample vials along a benchtop indexer at 30-800 mm/s, with DMSG switches confirming each 160 mm advance on the standard magnet.
Is the Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X160-40S the Right Cylinder?
If 100.5 N is too little, step up to the 20 mm bore (157.0 N push at 0.5 MPa) or the 25 mm bore (245.3 N). The 6 mm rod keeps a 160 mm travel light, but keep side loads off it and guide the part separately. FA flange and LB foot mounts, plus I and Y rod knuckles, cover most fixings, and the male rod thread is M6x1.0 with M5x0.8 ports. The stop screw only trims the extend stroke - if air drops, the piston still drifts, so do not rely on it to park a load.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) is standard for sensors
- ✓ Back cover (CA/U/CM) & mount (FA/LB/SDB)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion screws and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MACJ Stainless Steel Mini Adjustable Cylinder MACJ16X160-40S FAQ
At 0.5 MPa the 16 mm bore pushes 100.5 N and pulls 86.4 N; at 0.7 MPa that rises to 140.7 N push and 120.9 N pull, with a theoretical peak of 20.5 kgf at 1.0 MPa. Pressure range is 0.15-1.0 MPa (22-145 psi) and speed runs 30-800 mm/s on air filtered to 40 um.
No. The stop screw simply caps the extend stroke anywhere inside the 40 mm window; it is not a mid-stroke lock, and on air loss the piston drifts. Both ends carry a variable air cushion for soft landings, and FA flange or LB foot mounts suit most frames.
