Airtac MTG Stainless Steel Mini Cylinder MTG20X100S
The AirTAC Airtac MTG Stainless Steel Mini Cylinder MTG20X100S is a genuine single acting, pull (spring return) JIS-standard round-body mini air cylinder with a Ø20mm bore and 100mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ20 mm
- Stroke100 mm
- Port size1/8"
- Acting typeSingle acting, pull (spring return)
- Rod threadM8×1.25
- CushionFixed anti-impact bumper pads
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MTG Stainless Steel Mini Cylinder MTG20X100S
The AirTAC MTG20X100S is a single acting, spring-return PULL cylinder in the JIS round-body mini series: the internal spring holds the rod EXTENDED at rest, and compressed air RETRACTS (pulls) the rod on the work stroke. With a 20 mm bore and 100 mm stroke it delivers about 84.8 N of net pull at 0.5 MPa and 137.5 N at 0.7 MPa, already after the spring. That means one air line and one valve position do the work, so a realistic safe working pull is roughly 50 N, or about 5 kg of vertical load at the 0.6 derating rule of thumb. Minimum working pressure is 0.2 MPa (28 psi) and the speed range is 50 to 800 mm/s.
Construction suits damp and washdown corners of a line: a SUS304 stainless barrel, a hard-chrome (20 um) carbon-steel rod, riveted rolled covers, a two-way lubricant-storing piston seal and a fixed anti-impact bumper pad at the stroke end. The fitted magnet (the S code) accepts CMSG, DMSG or EMSG reed switches for end-of-stroke signalling, the port is 1/8" on every MTG bore, and the rod carries a male M8x1.25 thread. Mounting options include LB foot, FA flange, CB clevis and SDB pivot, plus I and Y rod knuckles. If you need two-way powered travel or a stroke beyond the 150 mm spring-return limit of this series, step up to the double-acting MG instead.
Airtac MTG Stainless Steel Mini Cylinder MTG20X100S Technical Specifications
| Model | Airtac MTG Stainless Steel Mini Cylinder MTG20X100S |
|---|---|
| Series | MTG JIS mini cylinder |
| Bore size | Ø20 mm |
| Stroke | 100 mm |
| Acting type | Single acting, pull (spring return) |
| Port size | 1/8" |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 150 mm |
Specifications follow the official AirTAC MG-series (JIS standard) datasheet. Barrel: SUS304 stainless steel (round-body, riveted construction); piston rod: carbon steel with 20µm hard-chrome plating. Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø20mm)
| Pressure | Pull force (spring return) |
|---|---|
| 0.5 MPa | 84.8 N |
| 0.7 MPa | 137.5 N |
Single-acting pull: the spring extends the rod; air retracts it. Forces already net the spring; minimum working pressure is 0.2 MPa.
Model Code: Airtac MTG Stainless Steel Mini Cylinder MTG20X100S
| MTG | JIS round-body mini cylinder (single-acting pull, spring-return). |
|---|---|
| 20 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
| FA / LB / CB / SDB | Mounting: FA flange, LB foot, CB clevis, SDB pivot bracket (with CB). |
MG-family variants: MG / MGC (double acting ±cushion), MSG / MTG (single acting push / pull), MGD / MGCD (double rod ±cushion). Accessories: LB foot, FA flange, CB clevis, SDB pivot block, plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MTG Stainless Steel Mini Cylinder MTG20X100S Is Used
Retract a locating pin
The spring keeps the pin extended for indexing, and the MTG20X100S pulls it clear on demand with about 84.8 N at 0.5 MPa; the fitted magnet signals the retracted position to the PLC.
Draw a light web or tape
Use the 100 mm pull stroke to draw film, tape or a light web through a guide, where the 84.8 to 137.5 N net pull at 0.5 to 0.7 MPa is enough and one air line keeps plumbing simple.
Close a sliding shutter or gate
Let the spring hold the shutter open and use air to pull it closed over 100 mm; on air loss the spring returns the shutter to its open rest position automatically.
Is the Airtac MTG Stainless Steel Mini Cylinder MTG20X100S the Right Cylinder?
Size the MTG20X100S by pull force, not bore alone: at 0.5 MPa this 20 mm bore gives 84.8 N net pull (about 8.6 kgf), the smallest in the MTG range. If your draw needs more, the MTG25 gives about 132.6 N and the MTG40 about 339.1 N at the same pressure. Remember the direction of power: the spring pushes the rod OUT and air PULLS it in, so the work stroke must be a retract, draw, close or tension motion, and on air loss the rod returns to its extended rest position rather than holding the load. The spring also caps standard strokes at 150 mm for this bore, so 100 mm is comfortably within range; for longer travel or powered return choose the double-acting MG. Check the 0.2 MPa (28 psi) minimum against your supply, confirm the 1/8" port and M8x1.25 male rod thread, pick LB, FA, CB or SDB mounting (I/Y knuckles available), and keep the S code if you want CMSG/DMSG/EMSG switch position feedback, which this model already has.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting (LB / FA / CB / SDB) & knuckle
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion/impact settings and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MTG Stainless Steel Mini Cylinder MTG20X100S FAQ
The 20 mm bore gives 84.8 N net pull at 0.5 MPa and 137.5 N at 0.7 MPa, already after the return spring. Operating pressure is 0.2 to 1.0 MPa (28 to 145 psi) with a 1.5 MPa (215 psi) proof pressure, working temperature -20 to +70 C, speed 50 to 800 mm/s, and air filtered to 40 um. The port is 1/8" and the rod thread is male M8x1.25.
In the MTG the spring EXTENDS the rod and air RETRACTS it, so the powered stroke is a pull and the rod fails to its extended rest position on air loss. The MSG is the mirror image: air pushes and the spring retracts. The MG is double acting, with air on both sides for powered two-way travel and strokes beyond the 150 mm spring-return limit. This S-coded model carries a magnet for CMSG, DMSG or EMSG switches; the fixed bumper pad softens the stroke end but is not a lock or brake.
