Airtac MTG Stainless Steel Mini Cylinder MTG20X125S
The AirTAC Airtac MTG Stainless Steel Mini Cylinder MTG20X125S is a genuine single acting, pull (spring return) JIS-standard round-body mini air cylinder with a Ø20mm bore and 125mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ20 mm
- Stroke125 mm
- Port size1/8"
- Acting typeSingle acting, pull (spring return)
- Rod threadM8×1.25
- CushionFixed anti-impact bumper pads
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MTG Stainless Steel Mini Cylinder MTG20X125S
The AirTAC MTG20X125S is a single acting PULL mini cylinder built to the JIS footprint: a 20 mm bore and 125 mm stroke in a round SUS304 stainless barrel with a hard-chrome plated rod and riveted covers. Because it is spring return, the internal spring holds the rod EXTENDED at rest, and compressed air applied through the 1/8" port RETRACTS (pulls) the rod on the work stroke. Net pull output, already after the spring, is 84.8 N at 0.5 MPa and 137.5 N at 0.7 MPa, with a minimum working pressure of 0.2 MPa (28 psi) and a speed range of 50-800 mm/s.
The magnet fitted on this -S version lets you mount CMSG, DMSG or EMSG switches for end-of-stroke signalling. The fixed anti-impact bumper pad softens the stroke ends but is not a lock or brake: on air loss the spring simply pushes the rod back out to its extended rest position, so the cylinder does not hold a load. A practical sizing insight: at a realistic 0.5 MPa supply, 84.8 N is roughly 8.6 kgf of pull, so halving it gives a safe working load of about 4 kg on a vertical draw. If you need two-way powered travel or a stroke beyond the 150 mm MTG standard limit, step up to the double-acting MG series.
Airtac MTG Stainless Steel Mini Cylinder MTG20X125S Technical Specifications
| Model | Airtac MTG Stainless Steel Mini Cylinder MTG20X125S |
|---|---|
| Series | MTG JIS mini cylinder |
| Bore size | Ø20 mm |
| Stroke | 125 mm |
| Acting type | Single acting, pull (spring return) |
| Port size | 1/8" |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 150 mm |
Specifications follow the official AirTAC MG-series (JIS standard) datasheet. Barrel: SUS304 stainless steel (round-body, riveted construction); piston rod: carbon steel with 20µm hard-chrome plating. Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø20mm)
| Pressure | Pull force (spring return) |
|---|---|
| 0.5 MPa | 84.8 N |
| 0.7 MPa | 137.5 N |
Single-acting pull: the spring extends the rod; air retracts it. Forces already net the spring; minimum working pressure is 0.2 MPa.
Model Code: Airtac MTG Stainless Steel Mini Cylinder MTG20X125S
| MTG | JIS round-body mini cylinder (single-acting pull, spring-return). |
|---|---|
| 20 | Bore size in mm. |
| ×125 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
| FA / LB / CB / SDB | Mounting: FA flange, LB foot, CB clevis, SDB pivot bracket (with CB). |
MG-family variants: MG / MGC (double acting ±cushion), MSG / MTG (single acting push / pull), MGD / MGCD (double rod ±cushion). Accessories: LB foot, FA flange, CB clevis, SDB pivot block, plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MTG Stainless Steel Mini Cylinder MTG20X125S Is Used
Retracting a locating pin
Air pulls the 8 mm rod in to withdraw a pin or latch from a fixture, and the spring re-extends it the moment pressure drops, giving a fail-safe extended rest position.
Drawing a tape or web under tension
With about 8.6 kgf of pull at 0.5 MPa (roughly a 4 kg safe working load), the cylinder draws light webs, tapes or film into position on packaging and converting lines.
Closing a shutter with position feedback
The fitted magnet and a CMSG or DMSG switch confirm the closed position, while the spring returns the shutter open on air loss, all from a single 1/8" air line.
Is the Airtac MTG Stainless Steel Mini Cylinder MTG20X125S the Right Cylinder?
Choose the MTG20X125S when your motion is a one-way pull (retract, draw, close or tension) and a spring can push the rod back out. At 20 mm bore it is the smallest MTG, delivering 84.8 N pull at 0.5 MPa and 137.5 N at 0.7 MPa; if that is marginal, move up to MTG25 (132.6 N at 0.5 MPa) or MTG32 (224.8 N). Remember the direction of power: the spring extends the rod, air retracts it, and the spring sets a 0.2 MPa (28 psi) minimum supply. The 125 mm stroke is within the 150 mm spring-return standard limit for this bore; longer strokes or two-way travel call for the double-acting MG. Mounting options are LB foot, FA flange, CB clevis and SDB pivot, plus I and Y rod knuckles; the -S magnet accepts CMSG / DMSG / EMSG switches. Ports are 1/8" on every MTG bore, threaded PT as standard.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting (LB / FA / CB / SDB) & knuckle
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion/impact settings and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MTG Stainless Steel Mini Cylinder MTG20X125S FAQ
Net pull (already after the spring) is 84.8 N at 0.5 MPa and 137.5 N at 0.7 MPa. Operating pressure is 0.2-1.0 MPa (28-145 psi) with a 1.5 MPa (215 psi) proof pressure, air filtered to 40 um, a temperature range of -20 to +70 C, and a speed range of 50-800 mm/s. The spring return sets the 0.2 MPa minimum.
In the MTG the spring extends the rod and air retracts (pulls) it, so only one air line is needed and the rod fails to its extended position on air loss. The MSG is the mirror image (spring retracts, air pushes), and the MG is double acting with powered travel both ways. The -S magnet on this model accepts CMSG / DMSG / EMSG switches, and the fixed bumper pad softens the stroke ends without locking or braking the load.
