Airtac MTG Stainless Steel Mini Cylinder MTG20X50S
The AirTAC Airtac MTG Stainless Steel Mini Cylinder MTG20X50S is a genuine single acting, pull (spring return) JIS-standard round-body mini air cylinder with a Ø20mm bore and 50mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ20 mm
- Stroke50 mm
- Port size1/8"
- Acting typeSingle acting, pull (spring return)
- Rod threadM8×1.25
- CushionFixed anti-impact bumper pads
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MTG Stainless Steel Mini Cylinder MTG20X50S
The MTG20X50S is a single acting, spring-return JIS mini cylinder with a 20 mm bore and 50 mm stroke, built for one-way pull work: the internal spring holds the rod extended at rest, and compressed air retracts (pulls) the rod on the work stroke. Because air acts on only one side of the piston, a single 1/8" port and one air line are all it needs. Net pull output, already after the spring, is 84.8 N at 0.5 MPa and 137.5 N at 0.7 MPa, with a minimum working pressure of 0.2 MPa and a speed range of 50 to 800 mm/s. If air is lost, the spring simply pushes the rod back out to its extended rest position.
Construction follows the JIS round-body mini format: a riveted SUS304 stainless barrel with a hard-chrome plated carbon steel rod (8 mm diameter, male thread M8x1.25), a two-way lubricant-storing piston seal, and a fixed anti-impact bumper pad that softens the stroke ends without locking or braking the load. The fitted magnet (the S in the code) allows CMSG, DMSG or EMSG switches to be mounted for end-of-stroke signalling. For sizing, treat the realistic working pull as roughly 60 percent of the rated figure, about 50 N, which is around 5 kg of safe continuous load at 0.5 MPa.
Airtac MTG Stainless Steel Mini Cylinder MTG20X50S Technical Specifications
| Model | Airtac MTG Stainless Steel Mini Cylinder MTG20X50S |
|---|---|
| Series | MTG JIS mini cylinder |
| Bore size | Ø20 mm |
| Stroke | 50 mm |
| Acting type | Single acting, pull (spring return) |
| Port size | 1/8" |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 150 mm |
Specifications follow the official AirTAC MG-series (JIS standard) datasheet. Barrel: SUS304 stainless steel (round-body, riveted construction); piston rod: carbon steel with 20µm hard-chrome plating. Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø20mm)
| Pressure | Pull force (spring return) |
|---|---|
| 0.5 MPa | 84.8 N |
| 0.7 MPa | 137.5 N |
Single-acting pull: the spring extends the rod; air retracts it. Forces already net the spring; minimum working pressure is 0.2 MPa.
Model Code: Airtac MTG Stainless Steel Mini Cylinder MTG20X50S
| MTG | JIS round-body mini cylinder (single-acting pull, spring-return). |
|---|---|
| 20 | Bore size in mm. |
| ×50 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
| FA / LB / CB / SDB | Mounting: FA flange, LB foot, CB clevis, SDB pivot bracket (with CB). |
MG-family variants: MG / MGC (double acting ±cushion), MSG / MTG (single acting push / pull), MGD / MGCD (double rod ±cushion). Accessories: LB foot, FA flange, CB clevis, SDB pivot block, plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MTG Stainless Steel Mini Cylinder MTG20X50S Is Used
Retracting a locating pin
Air pulls an 8 mm pin out of a fixture nest on each cycle; on air loss or shutdown the spring pushes the pin back out to its extended rest position, giving a predictable fail-safe state without a second valve port.
Closing a small machine shutter
The 84.8 N pull at 0.5 MPa is enough to slide a lightweight guard or shutter closed over an access window, while the spring reopens it the moment pressure drops.
Tensioning a light belt or web
Mounted on a pivoting idler with an SDB or CB mount, the cylinder draws the idler back to keep about 5 kg of safe working tension on a thin belt or film web.
Is the Airtac MTG Stainless Steel Mini Cylinder MTG20X50S the Right Cylinder?
Choose the MTG20X50S when your motion is a one-way pull of about 50 to 85 N and a 50 mm retract is enough: it is the smallest MTG bore, so step up to MTG25 for heavier draws (132.6 N at 0.5 MPa) or MTG32/MTG40 beyond that. Remember the direction of operation: the spring extends the rod and air retracts it, and the spring sets a 0.2 MPa minimum working pressure, so verify your supply stays above that. The spring return also caps standard strokes at 150 mm for this bore; for longer travel or powered movement in both directions, move to the double acting MG series. Mounting options are LB foot, FA flange, CB clevis and SDB pivot, with I and Y rod knuckles available, and the fitted magnet accepts CMSG, DMSG or EMSG position switches. Ports are 1/8" on every MTG bore, with PT thread as standard (G or NPT on request).
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting (LB / FA / CB / SDB) & knuckle
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion/impact settings and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MTG Stainless Steel Mini Cylinder MTG20X50S FAQ
Net pull output is 84.8 N at 0.5 MPa and 137.5 N at 0.7 MPa, already after the return spring. Operating pressure is 0.2 to 1.0 MPa (28 to 145 psi) with a proof pressure of 1.5 MPa (215 psi), temperature range -20 to +70 C, speed range 50 to 800 mm/s, and air filtered to 40 um. The port is 1/8" and the rod is 8 mm with an M8x1.25 male thread.
In the MTG the spring extends the rod and compressed air retracts (pulls) it, so only one air line is needed and the rod fails to its extended position on air loss; the fixed bumper pad softens the stroke end but is not a lock or brake. The MSG series is the opposite single acting type (air pushes, spring retracts), while the MG series is double acting with powered strokes in both directions and allows longer travel than the 150 mm spring-return limit. The fitted magnet on this S-coded model accepts CMSG, DMSG or EMSG switches.
