Airtac PTB Single Acting Pen-Type Cylinder PTB10X30CB
The AirTAC Airtac PTB Single Acting Pen-Type Cylinder PTB10X30CB is a single acting, pull type (spring extend) pen-size mini cylinder with a Ø10mm bore and 30mm stroke. A single air port drives the pull stroke; the built-in return spring resets the rod when air is released, so only one solenoid line is needed.
- BoreØ10 mm
- Stroke30 mm
- Port sizeM5×0.8
- Acting typePull, single acting
- Rod threadM8×1.0
- ReturnSpring
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PTB Single Acting Pen-Type Cylinder PTB10X30CB
The AirTAC PTB10X30CB is a JIS pen-size mini cylinder built for single-acting pull operation. Air entering the single M5x0.8 port retracts the Ø4 mm rod, while an internal spring pushes it back out upon exhaust release. This fail-safe extended state ensures your tooling returns home if air pressure drops. You get 23.5 N of net pull at 0.5 MPa, with the return spring force already deducted.
Featuring a SUS304 stainless barrel and a CB double clevis back cover, this unit handles pivoting loads easily. The slim body saves space on tight jigs. A fixed TPU bumper decelerates the stroke near the ends. Plan for a safe working load of roughly 14 N to account for seal friction and smooth travel.
Airtac PTB Single Acting Pen-Type Cylinder PTB10X30CB Technical Specifications
| Model | Airtac PTB Single Acting Pen-Type Cylinder PTB10X30CB |
|---|---|
| Series | PTB JIS pen-size mini cylinder |
| Bore size | Ø10 mm |
| Rod diameter | Ø4 mm |
| Stroke | 30 mm |
| Acting type | Single acting, pull type (spring extend) |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (pull by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod extended; applying air retracts it, and removing air lets the spring push the rod back out. Forces below are the NET spring-deducted values from the AirTAC thrust table. Confirm against the product label before installation.
Net Pull Force (Ø10mm)
| Pressure | Net pull force |
|---|---|
| 0.5 MPa | 23.5 N |
| 0.7 MPa (max) | 36.7 N |
These are the usable pull forces after the return spring is subtracted, taken directly from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PTB Single Acting Pen-Type Cylinder PTB10X30CB
| PTB | JIS pen-size single acting, pull type (spring extend) mini-cylinder series. |
|---|---|
| 10 | Bore size in mm. |
| ×30 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| R | Back cover: R axial inlet (bore-dependent). |
Mounting accessories: LB, FA, CJ. Related PB-family variants: PB (double acting), PSB (single-acting push), PBD (double rod), PBR (front-mount).
Where the Airtac PTB Single Acting Pen-Type Cylinder PTB10X30CB Is Used
Pivoting Hold-Down Clamp
Uses the CB clevis to swing clear of a part; air pulls the rod back to release, and the spring failsafe extends to clamp securely.
Wire Belt Tensioner
Applies steady tension by pulling back on a belt run; the spring maintains tension automatically when shop air is removed.
Retract-to-Open Gate
Air retracts the rod to pull a lightweight diverter gate open, letting the spring push it closed as a safe default state.
Is the Airtac PTB Single Acting Pen-Type Cylinder PTB10X30CB the Right Cylinder?
When sizing this 10 mm bore option, compare it to the 6 mm variant offering 7.1 N, or step up to the 12 mm bore providing 33.1 N of net pull at 0.5 MPa. The internal return spring demands a minimum 0.2 MPa operating pressure before the rod will move. Without live air, the spring reliably holds the rod extended.
The CB double clevis mount is ideal for applications requiring a pivoting articulation. The rod-end thread is M8x1.0. Because the rod is only 4 mm thick, avoid side loads and add an external linear bearing for off-axis forces.
Quick checklist
- ✓ Net pull force at your working pressure
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe extend on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
- check Do not dismantle the front or back cover.
Airtac PTB Single Acting Pen-Type Cylinder PTB10X30CB FAQ
The net pull force is 23.5 N at 0.5 MPa and 36.7 N at the 0.7 MPa maximum. The internal spring sets a 0.2 MPa minimum pressure before motion begins. If air is lost, the spring forces the rod into the extended position.
A fixed TPU bumper at each end absorbs impact over the final few millimeters of travel. Because it is not adjustable, you should meter-out the exhaust or add an external shock absorber when cycling real tooling mass at higher speeds. The spring handles the full extend stroke automatically.
