Airtac PTB Single Acting Pen-Type Cylinder PTB10X45SCB
The AirTAC Airtac PTB Single Acting Pen-Type Cylinder PTB10X45SCB is a single acting, pull type (spring extend) pen-size mini cylinder with a Ø10mm bore and 45mm stroke. A single air port drives the pull stroke; the built-in return spring resets the rod when air is released, so only one solenoid line is needed.
- BoreØ10 mm
- Stroke45 mm
- Port sizeM5×0.8
- Acting typePull, single acting
- Rod threadM8×1.0
- ReturnSpring
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PTB Single Acting Pen-Type Cylinder PTB10X45SCB
The AirTAC PTB10X45SCB is a JIS pen-size single-acting pull cylinder where air entering the single M5x0.8 port retracts the rod, and an internal spring pushes it back out upon exhaust. This fail-safe extended state is ideal for holding or returning to a home position when air pressure drops. It yields a net pull of 23.5 N at 0.5 MPa and 36.7 N at 0.7 MPa, with the return spring force already deducted.
Built with a SUS304 stainless barrel and a slim Ø10 mm body, it saves space in tight jigs. The CB double clevis allows pivoting mount integration. Because the powered stroke acts on the smaller rod-side annular area, this pull rating is lower than a matching push cylinder. The fixed TPU bumper decelerates motion at the end of the stroke, and the -S suffix indicates a built-in piston magnet for position sensing.
Airtac PTB Single Acting Pen-Type Cylinder PTB10X45SCB Technical Specifications
| Model | Airtac PTB Single Acting Pen-Type Cylinder PTB10X45SCB |
|---|---|
| Series | PTB JIS pen-size mini cylinder |
| Bore size | Ø10 mm |
| Rod diameter | Ø4 mm |
| Stroke | 45 mm |
| Acting type | Single acting, pull type (spring extend) |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (pull by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod extended; applying air retracts it, and removing air lets the spring push the rod back out. Forces below are the NET spring-deducted values from the AirTAC thrust table. Confirm against the product label before installation.
Net Pull Force (Ø10mm)
| Pressure | Net pull force |
|---|---|
| 0.5 MPa | 23.5 N |
| 0.7 MPa (max) | 36.7 N |
These are the usable pull forces after the return spring is subtracted, taken directly from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PTB Single Acting Pen-Type Cylinder PTB10X45SCB
| PTB | JIS pen-size single acting, pull type (spring extend) mini-cylinder series. |
|---|---|
| 10 | Bore size in mm. |
| ×45 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| R | Back cover: R axial inlet (bore-dependent). |
Mounting accessories: LB, FA, CJ. Related PB-family variants: PB (double acting), PSB (single-acting push), PBD (double rod), PBR (front-mount).
Where the Airtac PTB Single Acting Pen-Type Cylinder PTB10X45SCB Is Used
Hold-Down Clamp
Spring pressure keeps the clamp extended safely, while a single air line pulls the rod back to release the workpiece.
Wire Tensioner
Maintains steady tension on a wire or belt in the extended state, using air to momentarily slacken the line.
Retract-to-Open Gate
Air retracts the pin to open a diverter gate on a conveyor, and the spring failsafe closes it automatically.
Is the Airtac PTB Single Acting Pen-Type Cylinder PTB10X45SCB the Right Cylinder?
This 10 mm bore generates 23.5 N net pull at 0.5 MPa. If your task needs less force, the Ø6 bore offers 7.1 N; stepping up to the Ø12 bore provides 33.1 N. Plan for a safe working load of about 14 N (roughly 60% of the 0.5 MPa rating) to account for seal friction and smooth travel. For vertical lifts, expect to hold or pull around 1.2 kg with a sane 2:1 safety margin.
The internal return spring sets a minimum operating pressure of 0.2 MPa before motion begins, with a maximum limit of 0.7 MPa. The Ø4 mm rod is designed for coaxial thrust; over this 45 mm stroke, add an external linear bearing if the load is off-axis to prevent side-loading damage. Confirm the CB double clevis fits your pivot pin before ordering.
Quick checklist
- ✓ Net pull force at your working pressure
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe extend on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
- check Do not dismantle the front or back cover.
Airtac PTB Single Acting Pen-Type Cylinder PTB10X45SCB FAQ
The net pull force is 23.5 N at 0.5 MPa and 36.7 N at 0.7 MPa (maximum pressure). Because the internal spring opposes the air stroke, a minimum of 0.2 MPa is required before the rod begins to move. The spring holds the rod extended by default.
Yes, the -S suffix denotes a built-in piston magnet compatible with AirTAC reed or electronic solid-state switches. The cylinder uses a fixed TPU bumper at each end that decelerates the last few millimeters of travel; at high speeds with heavy tooling mass, meter-out the exhaust or add an external shock absorber.
