AirTAC SE Series · ISO 15552 Cylinder

Airtac SE50 Standard Cylinder SE50X125

The AirTAC SE50 Standard Cylinder SE50X125 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø50mm bore and 125mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ50 mm
  • Stroke125 mm
  • Port sizePT1/4
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 30 mm
$73.11 $80.61Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SE50 stroke, mounting and version on one page All SE50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SE50 Standard Cylinder SE50X125

The AirTAC SE50X125 is a double-acting, single-rod ISO 15552 profile cylinder delivering 982 N of push force and 825 N of pull force at 0.5 MPa. It features a square extruded aluminum barrel without external tie rods, yielding a compact footprint that mounts flush against machine frames while resisting corrosion.

This 50 mm bore unit utilizes a PT1/4 port and a 20 mm hard-chrome plated rod. Because this specific SKU lacks the -S magnet code, it is not position-sensor ready out of the box. The field-adjustable pneumatic cushioning at both stroke ends allows you to tune deceleration via a set screw, softening hard end stops during high-speed operations.

Airtac SE50 Standard Cylinder SE50X125 Technical Specifications

ModelAirtac SE50 Standard Cylinder SE50X125
SeriesSE ISO 15552 profile cylinder
Bore sizeØ50 mm
Stroke125 mm
Acting typeDouble acting
Port sizePT1/4
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa982 N825 N
0.7 MPa1374 N—
Max (@1.0 MPa)200 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE50 Standard Cylinder SE50X125

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
50Bore size in mm.
×125Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE50 Standard Cylinder SE50X125 Is Used

package_2

Carton Erecting Mechanisms

Drives the folding arms on vertical carton erectors, utilizing the 982 N push force at 0.5 MPa to reliably pop and fold heavy corrugated board blanks.

conveyor_belt

Pallet Divert and Gate Arms

Actuates routing gates on 50 mm bore conveyor lines, where the 825 N retract force easily pulls diverter arms out of the way for passing pallets.

precision_manufacturing

Secondary Machining Clamps

Secures aluminum castings at drilling stations, where the no-tie-rod extruded body allows tight multi-cylinder spacing without protruding hardware.

Is the Airtac SE50 Standard Cylinder SE50X125 the Right Cylinder?

If your application requires less force, stepping down to the 40 mm bore yields 628 N of push at 0.5 MPa, whereas upgrading to the 63 mm bore provides 1559 N of push for heavier loads. As a true ISO 15552 cylinder, this model is dimensionally interchangeable with other ISO 15552 profile cylinders, making it a direct replacement that reuses your existing mounting hardware and bore/stroke footprint.

Note that a plain SE cylinder cannot hold a load when air pressure is lost or a valve is centered; the piston will drift. If your 125 mm stroke application requires mid-stroke position holding without live pressure, consider the BSE rod lock variant or an external pilot-operated check valve.

AirtacDistr lists every SE50 order code with its price on one page at https://airtacdistr.com/products/airtac-se50-iso-air-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE50 Standard Cylinder SE50X125 FAQ

At 0.5 MPa, the SE50X125 provides 982 N of push force and 825 N of pull force. At 0.7 MPa, the push force increases to 1374 N. The maximum push force is 200 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.

Yes. The SE50X125 is built to the ISO 15552 / VDMA 24562 dimensional standard, making it a direct replacement for other ISO 15552 profile cylinders. It shares the exact same mounting interface and PT1/4 port locations, though you should verify your existing hardware compatibility.
