Airtac SE50 Standard Cylinder SE50X100
The AirTAC SE50 Standard Cylinder SE50X100 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø50mm bore and 100mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ50 mm
- Stroke100 mm
- Port sizePT1/4
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 30 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE50 Standard Cylinder SE50X100
The AirTAC SE50X100 is a double-acting single-rod ISO 15552 profile cylinder engineered to deliver 982 N of push force and 825 N of pull force at 0.5 MPa. Its square extruded aluminum barrel eliminates external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames while exposing no vulnerable hardware.
Because this specific SKU lacks the built-in magnet suffix, it operates without electronic position feedback; however, the end caps retain the standard sensor grooves for future retrofits. The field-adjustable pneumatic cushioning at both ends allows technicians to tune end-of-stroke deceleration via a set screw, softening hard impacts when cycling at speeds up to 800 mm/s.
Airtac SE50 Standard Cylinder SE50X100 Technical Specifications
| Model | Airtac SE50 Standard Cylinder SE50X100 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø50 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT1/4 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 825 N |
| 0.7 MPa | 1374 N | — |
| Max (@1.0 MPa) | 200 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE50 Standard Cylinder SE50X100
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 50 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE50 Standard Cylinder SE50X100 Is Used
Carton Erector Flap Folding
Provides the precise 982 N push at 0.5 MPa required to fold and square corrugated cardboard flaps on high-speed packaging lines before tape application.
Bottling Line Diverter Gate
Utilizes the 100 mm stroke to pivot lane guide rails, redirecting glass or PET bottles between packaging channels without stalling the conveyor flow.
CNC Fixture Clamping
Secures aluminum castings inside machining centers, using the adjustable end cushions to prevent harsh mechanical stops from deforming the workpiece.
Is the Airtac SE50 Standard Cylinder SE50X100 the Right Cylinder?
When sizing this 50 mm bore, stepping down to a 40 mm cylinder reduces the 0.5 MPa push output to 628 N, whereas stepping up to a 63 mm bore increases it to 1559 N. This makes the SE50X100 the optimal middle ground for mid-range actuation requiring a 100 mm stroke. As a dimensionally interchangeable ISO 15552 component, it serves as a direct replacement for any standard profile cylinder sharing the same 50 mm bore, 100 mm stroke, PT1/4 port thread, and mounting footprint.
Note that a standard double-acting cylinder relies on continuous air pressure to maintain its load; if pneumatic supply is lost or the valve centers, the piston will drift. For applications requiring true load holding upon air loss, consider the AirTAC BSE rod-lock variant. At 100 mm of stroke, side loading is minimal, but external guides should still be used to prevent rod-bearing wear if the load is not axially rigid.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE50 Standard Cylinder SE50X100 FAQ
At 0.5 MPa, the SE50X100 delivers 982 N of push force and 825 N of pull force. At 0.7 MPa, the push force increases to 1374 N. The maximum push force is 200 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.
Yes. The SE50X100 is a true ISO 15552 profile cylinder, making it dimensionally interchangeable with other ISO 15552 cylinders of the same bore and stroke. You can reuse existing mounting hardware, but note this specific SKU lacks a position-sensing magnet.
