The AirTAC SE50 Standard Cylinder SE50X160 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø50mm bore and 160mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
The AirTAC SE50X160 is a double-acting single-rod ISO 15552 profile cylinder delivering 982 N of push force at 0.5 MPa. Because it uses an extruded aluminum square barrel without external tie rods, the body is highly corrosion-resistant and mounts flush against machine frames, saving valuable space in tight assemblies.
This 50 mm bore unit features a 160 mm stroke and a field-adjustable air cushion at both ends to decelerate the piston smoothly near the end of travel. This specific SKU is built without a magnet, meaning it is not ready out-of-the-box for CMSE or DMSE position sensors without modification.
| Model | Airtac SE50 Standard Cylinder SE50X160 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø50 mm |
| Stroke | 160 mm |
| Acting type | Double acting |
| Port size | PT1/4 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 825 N |
| 0.7 MPa | 1374 N | — |
| Max (@1.0 MPa) | 200 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 50 | Bore size in mm. |
| ×160 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Uses the 982 N push force to smoothly open and fold corrugated cardboard flaps on continuous packaging lines.
The 160 mm stroke actuates routing gates to sort packages, relying on the compact tie-rod-free profile for tight frame clearances.
Secures aluminum castings during machining, utilizing the field-adjustable cushion to soften hard end stops at high speeds.
If your application requires less force, stepping down to the 40 mm bore yields 628 N of push at 0.5 MPa, while moving up to the 63 mm bore provides 1559 N. Because this is a standard 160 mm stroke, it serves as a direct replacement for any ISO 15552 cylinder with matching 50 mm bore, PT1/4 port, and basic mounting footprint.
Note that a plain SE cylinder cannot hold a load if air pressure is lost; the adjustable cushion only decelerates the piston near stroke end rather than locking it. For applications needing secure position holding, consider the BSE rod lock variant.
AirtacDistr lists every SE50 order code with its price on one page at https://airtacdistr.com/products/airtac-se50-iso-air-cylinder
Quick checklist
At 0.5 MPa, the push force is 982 N and the pull force is 825 N. At 0.7 MPa, the push force is 1374 N. The maximum push force is 200 kgf at 1.0 MPa.
Yes, the SE50X160 is dimensionally interchangeable per ISO 15552 standards, meaning it shares the exact same mounting footprint and PT1/4 port size as comparable profile cylinders from other manufacturers.
