AirTAC SE Series · ISO 15552 Cylinder

Airtac SE50 Standard Cylinder SE50X250

The AirTAC SE50 Standard Cylinder SE50X250 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø50mm bore and 250mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ50 mm
  • Stroke250 mm
  • Port sizePT1/4
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 30 mm
$88.62 $96.12Save 7% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SE50 stroke, mounting and version on one page All SE50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SE50 Standard Cylinder SE50X250

The AirTAC SE50X250 is a double-acting single-rod ISO 15552 profile cylinder engineered to deliver 982 N of push force at 0.5 MPa. Its square extruded aluminum barrel omits external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames while exposing standardized ISO 15552 interface dimensions for universal hardware matching.

This 50 mm bore unit travels a 250 mm stroke and relies on field-adjustable pneumatic cushioning at both ends to soften hard end stops. Because this specific SKU lacks the -S magnet suffix, it does not support AirTAC CMSE or DMSE position sensors without modification.

Airtac SE50 Standard Cylinder SE50X250 Technical Specifications

ModelAirtac SE50 Standard Cylinder SE50X250
SeriesSE ISO 15552 profile cylinder
Bore sizeØ50 mm
Stroke250 mm
Acting typeDouble acting
Port sizePT1/4
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa982 N825 N
0.7 MPa1374 N—
Max (@1.0 MPa)200 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE50 Standard Cylinder SE50X250

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
50Bore size in mm.
×250Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE50 Standard Cylinder SE50X250 Is Used

conveyor_belt

Package Diverter

Actuates a routing gate on a packaging conveyor, using the 982 N push force to reliably pivot heavy cardboard cartons at 250 mm stroke.

precision_manufacturing

CNC Lathe Door

Opens and closes a sliding machine safety shield, utilizing the adjustable end cushions to prevent slamming at the end of the 250 mm travel.

science

Lab Sample Ejector

Pushes processed test tubes out of a centrifuge carousel, relying on the compact tie-rod-free profile to fit within tight analytical equipment.

Is the Airtac SE50 Standard Cylinder SE50X250 the Right Cylinder?

Choosing this 50 mm bore makes sense when you need 982 N push at 0.5 MPa. If your load is lighter, stepping down to the 40 mm bore yields 628 N push; if your application demands more force, stepping up to the 63 mm bore provides 1559 N push. For a 250 mm stroke, the 20 mm rod and M16x1.5 thread carry moderate side loads, but you should still use an external guide to prevent rod-bearing bending.

As a standard double-acting cylinder, the SE50X250 will drift if air is lost or the valve is centered. It cannot hold a load without live pressure, so add a BSE rod lock for fail-safe positioning. To retrofit an existing machine, match the 50 mm bore, 250 mm stroke, PT1/4 port, and your required mounting accessory.

AirtacDistr lists every SE50 order code with its price on one page at https://airtacdistr.com/products/airtac-se50-iso-air-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE50 Standard Cylinder SE50X250 FAQ

At 0.5 MPa, the SE50X250 provides 982 N of push force and 825 N of pull force. At 0.7 MPa, the push force is 1374 N. The maximum push force is 200 kgf at 1.0 MPa.

No, the adjustable air cushion at both ends only decelerates the piston near the stroke limits and does not act as a brake. The cylinder will drift if air pressure is lost. For position holding, use a BSE rod lock variant.
