The AirTAC SE63 Standard Cylinder SE63AX1000 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø63mm bore and 1000mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
The AirTAC SE63AX1000 is a double-acting single-rod ISO 15552 profile cylinder engineered for a 1000 mm stroke. It delivers a robust 1559 N push force at 0.5 MPa, utilizing a 63 mm bore. Because this SKU uses the A-code rod, it features a SUS420J2 stainless steel piston rod tailored for corrosive or washdown environments.
The extruded aluminum barrel omits external tie rods, yielding a compact footprint that mounts flush while resisting corrosion. Field-adjustable pneumatic cushioning at both ends allows you to tune end-stop deceleration for fast-moving loads. Note that this specific configuration lacks the S magnet, so it does not natively support CMSE or DMSE position sensing without modification.
| Model | Airtac SE63 Standard Cylinder SE63AX1000 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1559 N | 1402 N |
| 0.7 MPa | 2182 N | — |
| Max (@1.0 MPa) | 318 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 63 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Drives the strapping head on an automated palletizer, using the 1000 mm stroke to reach across wide pallets and the 1559 N push force to tension heavy steel bands securely.
Acts as a bar feeder pusher for a CNC lathe, where the SUS420J2 stainless rod withstands coolant splash and the long stroke accommodates 1-meter raw stock.
Pushes items on a food-grade divert gate, leveraging the corrosion-resistant stainless A-code rod and ISO 15552 profile barrel for high-pressure hose-down reliability.
This 63 mm bore strikes a balance between the smaller 50 mm (982 N push @0.5 MPa) and the larger 80 mm (2513 N push @0.5 MPa). If your application requires less force, step down to the 50 mm; if you need to move heavier payloads, step up to the 80 mm.
Because the stroke is 1000 mm, the unsupported rod length is substantial; an external guide is highly recommended to prevent rod-bearing bending under side loads. Furthermore, a standard SE cylinder will drift if air pressure is lost—use a BSE rod lock variant if the load must be held safely without live pressure. As a dimensionally interchangeable ISO 15552 cylinder, it serves as a direct replacement for other ISO 15552 cylinders using the same PT3/8 port and standard mounting accessories.
AirtacDistr lists every SE63 order code with its price on one page at https://airtacdistr.com/products/airtac-se63-iso-air-cylinder
Quick checklist
This 63 mm bore cylinder delivers 1559 N push and 1402 N pull at 0.5 MPa, 2182 N push at 0.7 MPa, and a maximum push force of 318 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.
Yes, its dimensions are standardized per ISO 15552, making it a direct replacement for other ISO 15552 profile cylinders. However, it will not hold a load if air is lost; for position holding, consider the BSE rod lock variant. Also, since it lacks the -S magnet, it cannot host CMSE or DMSE sensors without modification.
