Airtac SE63 Standard Cylinder SE63X50
The AirTAC SE63 Standard Cylinder SE63X50 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø63mm bore and 50mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ63 mm
- Stroke50 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 36 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE63 Standard Cylinder SE63X50
The AirTAC SE63X50 is a double-acting, single-rod ISO 15552 profile cylinder engineered to deliver 1559 N of push force and 1402 N of pull force at 0.5 MPa. Designed with a 63 mm bore and a 50 mm stroke, it operates efficiently between 30-800 mm/s using a PT3/8 port.
This unit features a square extruded aluminum barrel without external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machinery. The field-adjustable pneumatic cushioning at both ends allows technicians to tune end-of-stroke deceleration for fast cycling, while the integrated M16x1.5 rod thread handles high side loads.
Airtac SE63 Standard Cylinder SE63X50 Technical Specifications
| Model | Airtac SE63 Standard Cylinder SE63X50 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 50 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1559 N | 1402 N |
| 0.7 MPa | 2182 N | — |
| Max (@1.0 MPa) | 318 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE63 Standard Cylinder SE63X50
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 63 | Bore size in mm. |
| ×50 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE63 Standard Cylinder SE63X50 Is Used
Carton Erector Jaws
Provides the 1559 N push force required to snap corrugated cardboard cartons open rapidly on high-speed packaging lines.
Pallet Diverter Arm
Uses the 50 mm stroke to push heavy wooden pallets onto secondary conveyor lanes without overtravel or excessive footprint.
CNC Door Interlock
Actuates heavy machine tool safety doors, relying on the adjustable end cushions to prevent slamming at 800 mm/s.
Is the Airtac SE63 Standard Cylinder SE63X50 the Right Cylinder?
If your application requires less force, stepping down to the 50 mm bore yields 982 N of push at 0.5 MPa, whereas scaling up to the 80 mm bore provides 2513 N. This SE63X50 is dimensionally interchangeable per ISO 15552, allowing a direct replacement for other standard profile cylinders without altering mounting footprints. Note that this specific SKU lacks a built-in magnet, so position sensing is not available out of the box. Furthermore, because it is a standard double-acting cylinder, it cannot hold a load if air pressure is lost; applications requiring mid-stroke holding or fail-safe braking should utilize an external pilot-operated check valve or the BSE rod lock variant.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE63 Standard Cylinder SE63X50 FAQ
The SE63X50 generates 1559 N of push force and 1402 N of pull force at 0.5 MPa. At 0.7 MPa, the push force is 2182 N, with a maximum push capacity of 318 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.
Yes, the SE63X50 is dimensionally interchangeable per ISO 15552, meaning it shares the exact same mounting and rod thread footprint as other standard profile cylinders, allowing for a seamless direct retrofit.
