Airtac SE63 Standard Cylinder SE63X100
The AirTAC SE63 Standard Cylinder SE63X100 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø63mm bore and 100mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ63 mm
- Stroke100 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 36 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE63 Standard Cylinder SE63X100
The AirTAC SE63X100 is a double-acting single-rod ISO 15552 profile cylinder engineered to deliver a 1559 N push force at 0.5 MPa. Its square extruded aluminum barrel eliminates external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames.
This 63 mm bore unit features a 20 mm hard-chrome piston rod and a PT3/8 port. Field-adjustable pneumatic cushioning at both ends allows you to tune end-of-stroke deceleration for moving loads, while the standard extrusion omits a sensor magnet on this specific SKU.
Airtac SE63 Standard Cylinder SE63X100 Technical Specifications
| Model | Airtac SE63 Standard Cylinder SE63X100 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1559 N | 1402 N |
| 0.7 MPa | 2182 N | — |
| Max (@1.0 MPa) | 318 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE63 Standard Cylinder SE63X100
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 63 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE63 Standard Cylinder SE63X100 Is Used
Pallet Diverting
Provides the 1559 N push force needed to deflect heavy pallets onto secondary packaging lines at 100 mm stroke.
CNC Fixture Clamping
Secures cast aluminum engine blocks during machining, utilizing the 20 mm rod to handle high side-load stresses.
Carton Forming
Drives the folding mechanism on corrugated box erecting machines, relying on adjustable cushioning to prevent hard end impacts.
Is the Airtac SE63 Standard Cylinder SE63X100 the Right Cylinder?
Selecting this 63 mm bore makes sense when your application requires the 1559 N push at 0.5 MPa. If you need less force, stepping down to the 50 mm bore yields 982 N push, whereas stepping up to the 80 mm bore provides 2513 N push. Because this is a standard double-acting cylinder, it will drift if air pressure is lost or the valve centers; use a BSE rod lock variant if you need strict position holding.
As a true ISO 15552 profile cylinder, the SE63X100 is dimensionally interchangeable with other ISO 15552 cylinders, simplifying retrofits. It uses a PT3/8 port and shares standardized mounting accessories like FA or LB brackets across the ISO footprint.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE63 Standard Cylinder SE63X100 FAQ
The SE63X100 delivers a push force of 1559 N and a pull force of 1402 N at 0.5 MPa. At 0.7 MPa, the push force is 2182 N, with a maximum push capacity of 318 kgf at 1.0 MPa. The operating speed range is 30-800 mm/s.
Yes, the SE63X100 is dimensionally interchangeable per ISO 15552 standards. You can use it as a direct replacement for other ISO 15552 profile cylinders, matching the 63 mm bore, 100 mm stroke, and PT3/8 porting.
