Airtac SE63 Standard Cylinder SE63X200
The AirTAC SE63 Standard Cylinder SE63X200 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø63mm bore and 200mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ63 mm
- Stroke200 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 36 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE63 Standard Cylinder SE63X200
The AirTAC SE63X200 is a double-acting single-rod profile cylinder built to the ISO 15552 standard, delivering a robust 1559 N push force at 0.5 MPa. Its square extruded aluminum barrel eliminates external tie rods, yielding a compact footprint that mounts flush against machine frames while resisting corrosion.
This 63 mm bore unit features field-adjustable pneumatic cushioning at both ends to decelerate loads smoothly over its 200 mm stroke. Note that this specific SKU is configured without a sensor magnet, so it does not support direct CMSE or DMSE position detection out of the box.
Airtac SE63 Standard Cylinder SE63X200 Technical Specifications
| Model | Airtac SE63 Standard Cylinder SE63X200 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 200 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1559 N | 1402 N |
| 0.7 MPa | 2182 N | — |
| Max (@1.0 MPa) | 318 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE63 Standard Cylinder SE63X200
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 63 | Bore size in mm. |
| ×200 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE63 Standard Cylinder SE63X200 Is Used
Pallet Diverters
Provides the 1559 N push force needed to deflect heavy wooden pallets across transfer lines without bouncing back.
Case Erectors
Extends 200 mm to fold and seal corrugated cardboard flaps, utilizing the adjustable cushion to prevent crushing the board.
Metal Stamping Ejectors
Kicks stamped aluminum parts out of progressive dies, relying on the 20 mm hard-chrome rod to absorb brief lateral impacts.
Is the Airtac SE63 Standard Cylinder SE63X200 the Right Cylinder?
Choosing this 63 mm bore makes sense when you need approximately 1559 N of push at 0.5 MPa. If your load is lighter, stepping down to the 50 mm bore yields 982 N of push, whereas stepping up to the 80 mm bore provides 2513 N for heavier demands. Because the 200 mm stroke is under the 300 mm threshold, side-load stress on the rod bearing is moderate, though external guides are still recommended for rigid loads.
As a dimensionally interchangeable ISO 15552 cylinder, it serves as a direct replacement for other standard profile cylinders, utilizing the same PT3/8 ports and mounting accessories. Keep in mind that the adjustable air cushion only softens end-of-stroke impacts; it is not a locking device, so loads will drift if air pressure is lost.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE63 Standard Cylinder SE63X200 FAQ
At 0.5 MPa, this 63 mm bore cylinder provides 1559 N of push force and 1402 N of pull force. At 0.7 MPa, the push force increases to 2182 N, with a maximum push capacity of 318 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.
Yes, the SE63X200 is dimensionally interchangeable per ISO 15552 standards. You can use it as a direct replacement for other ISO 15552 profile cylinders of the same bore and stroke, reusing existing mounting hardware like FA or LB brackets.
