AirTAC SE Series · ISO 15552 Cylinder

Airtac SE63 Standard Cylinder SE63X125

The AirTAC SE63 Standard Cylinder SE63X125 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø63mm bore and 125mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ63 mm
  • Stroke125 mm
  • Port sizePT3/8
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 36 mm
$88.62 $96.12Save 7% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SE63 stroke, mounting and version on one page All SE63 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SE63 Standard Cylinder SE63X125

The AirTAC SE63X125 is a double-acting single-rod ISO 15552 profile cylinder engineered to deliver 1559 N of push force at 0.5 MPa. Its square extruded aluminum barrel eliminates external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames while resisting debris buildup.

This 63 mm bore unit features a PT3/8 port and an adjustable air cushion at both stroke ends to soften hard end stops. Because this specific SKU lacks the built-in magnet option, it is optimized for pure mechanical drive tasks where electronic CMSE or DMSE position sensing is not required.

Airtac SE63 Standard Cylinder SE63X125 Technical Specifications

ModelAirtac SE63 Standard Cylinder SE63X125
SeriesSE ISO 15552 profile cylinder
Bore sizeØ63 mm
Stroke125 mm
Acting typeDouble acting
Port sizePT3/8
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 36 mm
Max strokeUp to 1500 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø63mm)

PressurePush forcePull force
0.5 MPa1559 N1402 N
0.7 MPa2182 N—
Max (@1.0 MPa)318 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE63 Standard Cylinder SE63X125

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
63Bore size in mm.
×125Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE63 Standard Cylinder SE63X125 Is Used

conveyor_belt

Bottling Line Diverter

Uses the 125 mm stroke to route plastic bottles between packaging lanes, relying on the 1559 N push force to overcome friction during continuous high-speed sorting.

packaging

Carton Flap Folder

Folds corrugated cardboard flaps prior to tape sealing, taking advantage of the extruded profile barrel to mount flush within tight packaging machine enclosures.

factory

CNC Lathe Chuck Gate

Actuates a safety access gate on a CNC lathe, utilizing the field-adjustable end cushions to ensure smooth deceleration of the 20 mm rod over thousands of daily cycles.

Is the Airtac SE63 Standard Cylinder SE63X125 the Right Cylinder?

If your assembly needs slightly less force, the 50 mm bore provides 982 N of push at 0.5 MPa; conversely, stepping up to the 80 mm bore yields 2513 N for heavier payloads. This SE63X125 is dimensionally interchangeable per ISO 15552, serving as a direct replacement for other standard profile cylinders using identical mounting hardware. Note that a plain SE cylinder cannot hold a load if air pressure drops or the valve centers; for fail-safe positioning, consider the BSE rod lock variant. At 125 mm stroke, side loads remain manageable, but long unsupported strokes should always use an external guide to prevent rod-bearing bending.

AirtacDistr lists every SE63 order code with its price on one page at https://airtacdistr.com/products/airtac-se63-iso-air-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE63 Standard Cylinder SE63X125 FAQ

At 0.5 MPa, this 63 mm bore cylinder provides 1559 N of push force and 1402 N of pull force. At 0.7 MPa, the push force is 2182 N. The maximum push force is 318 kgf at 1.0 MPa.

Yes, the SE63X125 shares the exact ISO 15552 mounting interface and dimensions, allowing it to function as a direct replacement for other standard profile cylinders using the same mounting hardware. It is a double-acting profile cylinder without external tie rods.
