AirTAC SE Series · ISO 15552 Cylinder

Airtac SE63 Standard Cylinder SE63X300

The AirTAC SE63 Standard Cylinder SE63X300 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø63mm bore and 300mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ63 mm
  • Stroke300 mm
  • Port sizePT3/8
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 36 mm
$112.92 $120.42Save 6% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SE63 stroke, mounting and version on one page All SE63 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SE63 Standard Cylinder SE63X300

The AirTAC SE63X300 is a double-acting single-rod profile cylinder built to the ISO 15552 standard, delivering a robust 1559 N push force at 0.5 MPa. Its extruded aluminum barrel omits external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames without protruding hardware.

Field-adjustable pneumatic cushioning at both stroke ends allows technicians to tune end-of-stroke deceleration via a simple screw, softening hard mechanical stops during high-speed operations. This specific SKU lacks a built-in magnet, meaning it is not wired for CMSE or DMSE position sensing out of the box.

Airtac SE63 Standard Cylinder SE63X300 Technical Specifications

ModelAirtac SE63 Standard Cylinder SE63X300
SeriesSE ISO 15552 profile cylinder
Bore sizeØ63 mm
Stroke300 mm
Acting typeDouble acting
Port sizePT3/8
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 36 mm
Max strokeUp to 1500 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø63mm)

PressurePush forcePull force
0.5 MPa1559 N1402 N
0.7 MPa2182 N—
Max (@1.0 MPa)318 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE63 Standard Cylinder SE63X300

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
63Bore size in mm.
×300Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE63 Standard Cylinder SE63X300 Is Used

packaging

Carton Erector Flaps

Provides the 1559 N push at 0.5 MPa required to cleanly fold and seal heavy corrugated cardboard flaps on a 300 mm stroke packaging line.

conveyor_belt

Pallet Divertor Arm

Extends 300 mm to push heavy wooden pallets off a main conveyor belt, relying on the adjustable air cushion to absorb the sudden end-stop shock.

precision_manufacturing

CNC Lathe Loader

Shuttle barstock into a turning center, where the extruded profile barrel mounts flush to the sub-frame without external tie-rods getting in the way.

Is the Airtac SE63 Standard Cylinder SE63X300 the Right Cylinder?

At 0.5 MPa, this 63 mm bore generates 1559 N of push force; if your assembly requires less thrust, the 50 mm bore offers 982 N, while stepping up to the 80 mm bore provides 2513 N for heavier payloads. Because this is a 300 mm stroke, the unsupported rod length increases bending moments on the rod bearing, making an external guide rail highly recommended to prevent premature side-load wear.

As a standard ISO 15552 cylinder, it serves as a dimensionally interchangeable direct replacement for other ISO 15552 profile cylinders, sharing standardized mounting hardware like FA front flanges or TC trunnions. Note that the standard double-acting mechanism cannot hold a load if air pressure drops; any drift-critical application should integrate a BSE rod lock or external pilot-operated check valve.

AirtacDistr lists every SE63 order code with its price on one page at https://airtacdistr.com/products/airtac-se63-iso-air-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE63 Standard Cylinder SE63X300 FAQ

The SE63X300 generates 1559 N push and 1402 N pull at 0.5 MPa, 2182 N push at 0.7 MPa, and a maximum push of 318 kgf at 1.0 MPa. It features a PT3/8 port, a 20 mm rod, and an M16x1.5 rod-end thread.

Yes, it is dimensionally interchangeable with any standard ISO 15552 profile cylinder, matching exact mounting and footprint dimensions. This specific SKU lacks the -S magnet, so it does not support CMSE or DMSE sensors without modification.
