Airtac SUJ Adjustable Cylinder SUJ100X120-100TC
2. Features specially profiled bidirectional piston sealing structure with compact dimensions and integrated oil reservoir design;
3. Constructed with reinforced octagonal aluminum tubing, rodless configuration demonstrating enhanced corrosion resistance;
4. Maintains more compact length compared to ISO 15552 standard cylinders at equivalent bore sizes;
5. Incorporates adjustable cushioning mechanism for smooth stroke termination;
6. Mounting accessories fully compatible with SC series cylinder components;
7. Utilizes high-temperature resistant seals ensuring reliable operation at 150°C ambient conditions.
Category: Standard Cylinders, Brand: AIRTAC, Series: SUJ
AirTAC SUJ Adjustable Cylinder SUJ100X120-100TC Specifications
- Model: SUJ100X120-100TC
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø100 mm
- Stroke: 120 mm (Max adjustable range: ±50 mm)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable elastic cushion (both ends)
- Mounting style: Front flange with TC-type mounting slots
- Operating temperature: -20℃ to 80℃
- Material: Aluminum alloy barrel, CRCA steel rod
- Rod end thread: M20×1.5
- Port size: G3/8 (NPT1/2 optional)
- Weight: 5.8 kg (without accessories)
- Dimensions: 350mm(L) × 118mm(W) × 118mm(H)
- Piston seal: HNBR with wear-resistant ring
- Rod protection: Chrome-plated surface (25μm thickness)
- ISO standard: 15552 compliant
Heavy-duty adjustable stroke cylinder with precision positioning capability, featuring dual locking nuts for stroke adjustment (±50mm range). The hardened piston rod and triple sealing system ensure reliable performance in high-cycle applications. Includes built-in magnetic sensor slot for position feedback compatibility.
- Die casting machine ejection systems
- Automotive welding fixture positioning
- Palletizing robot end-effector control
- Injection molding machine core-pull mechanisms
- Steel mill conveyor gate actuators
Installation note:
Use locknuts (included) to secure stroke adjustment. Lubricate through port lubricators
with ISO VG32 hydraulic oil. Avoid side loads exceeding 200N. For vertical mounting,
install rod-down orientation to prevent seal wear.
- Magnetic sensor: D-A93 (IP67 rated)
- Rod end adapters: RE-20M series
- Heat-resistant seal kit (-30℃ to 150℃)
| Property | Property Value |
|---|---|
| sku | SUJ100X120-100TC |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 120mm |
