Airtac SUJ Adjustable Cylinder SUJ100X120-30SFA
2. Features specially profiled bidirectional piston sealing structure with compact dimensions and integrated oil reservoir design;
3. Constructed with reinforced octagonal aluminum tubing, rodless configuration demonstrating enhanced corrosion resistance;
4. Maintains more compact length compared to ISO 15552 standard cylinders at equivalent bore sizes;
5. Incorporates adjustable cushioning mechanism for smooth stroke termination;
6. Mounting accessories fully compatible with SC series cylinder components;
7. Utilizes high-temperature resistant seals ensuring reliable operation at 150°C ambient conditions.
Category: Standard Cylinders, Brand: AIRTAC, Series: SUJ
AirTAC SUJ Adjustable Cylinder SUJ100X120-30SFA Technical Details
- Model: SUJ100X120-30SFA
- Type: Double-acting adjustable stroke cylinder
- Bore size: 100mm
- Stroke: 120mm (adjustable)
- Operating pressure: 0.1-1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: G3/8 (ISO standard)
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Basic type (axial mounting)
- Material: Aluminum alloy tube, chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Weight: ~5.2kg (including accessories)
- Dimensions: 300mm(L) × 100mm(W) × 100mm(H)
- Rod thread: M20×1.5
- Protection class: IP54 (standard sealing)
High-precision adjustable stroke cylinder with magnetic piston for position feedback compatibility. Features dual adjustable cushions for smooth end-of-stroke deceleration and integrated mounting grooves for flexible installation. The chrome-plated piston rod provides enhanced corrosion resistance in humid environments.
- Position-adjustable clamping systems in CNC machinery
- Variable height work platforms in automotive assembly
- Material handling with adjustable gripping positions
- Packaging line product height compensation
- Printing press roller engagement mechanisms
Installation note:
Use locknuts (included) for stroke adjustment. Lubricate with ISO VG32 hydraulic oil
if operating below -10℃. Maintain 0.3-0.5mm clearance between stopper and cylinder
during adjustment. Requires 40μm filtered air with 1-3 drops/m³ lubricant.
- Max side load capacity: 180N at mid-stroke
- Repeat positioning accuracy: ±0.5mm
- Max piston speed: 500mm/s
- Service life: 5,000km (under standard conditions)
| Property | Property Value |
|---|---|
| sku | SUJ100X120-30SFA |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 120mm |
