Airtac TACE Guided Compact Cylinder TACE16X15
The AirTAC Airtac TACE Guided Compact Cylinder TACE16X15 is a genuine double acting, non-rotating ISO 21287 compact air cylinder with a Ø16mm bore and 15mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ16 mm
- Stroke15 mm
- Port sizeM5×0.8
- Acting typeDouble acting, non-rotating
- Rod threadM4×0.7
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACE Guided Compact Cylinder TACE16X15
The TACE16X15 is a double acting, non-rotating compact cylinder built to ISO 21287: a 16 mm bore with a 15 mm stroke, an 8 mm hard-chrome-plated S45C rod and M5x0.8 ports. At 0.5 MPa it pushes 100.5 N and pulls 75.4 N, rising to 140.7 N on the extend stroke at 0.7 MPa. Twin guide rods on a yoke stop the tooling rotating and carry side load, so a gripper or plate stays square without an external guide.
The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so this 15 mm stroke tucks into tight jigs, guards and small pick-and-place heads. As a working figure, plan for roughly 60 N of real push at 0.5 MPa, enough to lift about 5 kg vertically with a 2:1 margin. A fixed TPU bumper absorbs end-of-stroke energy at both ends, and the roller-burnished, hard-anodized aluminium body resists wear. The magnet is not fitted on this code; order the optional -S version if you want CMSE or DMSE switch sensing.
Airtac TACE Guided Compact Cylinder TACE16X15 Technical Specifications
| Model | Airtac TACE Guided Compact Cylinder TACE16X15 |
|---|---|
| Series | TACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø16 mm |
| Stroke | 15 mm |
| Acting type | Double acting, non-rotating |
| Port size | M5×0.8 |
| Rod thread | M4×0.7 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 75 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø16mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 101 N | 75 N |
| 0.7 MPa | 141 N | 106 N |
| Max (@1.0 MPa) | 21 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin. Twin guide rods stop the tooling rotating.
Model Code: Airtac TACE Guided Compact Cylinder TACE16X15
| TACE | ISO 21287 compact cylinder (non-rotating (twin-guide yoke)). |
|---|---|
| 16 | Bore size in mm. |
| ×15 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACE Guided Compact Cylinder TACE16X15 Is Used
Drilling fixture clamp
Clamps a machined aluminium bracket against a drill jig. The 15 mm stroke is enough to clear part loading, and 100.5 N at 0.5 MPa holds the bracket square while the hole is cut.
Reject gate on a filling line
Kicks underweight bottles off a conveyor into a bin. The twin-guide yoke keeps the pusher paddle from twisting under side load, and the short body fits beside the guard rail.
PCB tray indexing
Advances a small electronics tray one slot per cycle in a test station. At 30-500 mm/s the stroke completes in a fraction of a second, and the female M4x0.7 thread mounts the index finger directly.
Is the Airtac TACE Guided Compact Cylinder TACE16X15 the Right Cylinder?
Between the 12 mm bore (56.5 N push at 0.5 MPa) and the 20 mm bore (157.1 N push at 0.5 MPa), the 16 mm TACE16X15 sits in the light-clamp and small-part-handling band. It runs on 0.15-1.0 MPa (22-145 psi) filtered air at 30-500 mm/s, and the female M4x0.7 rod thread takes standard tooling directly. It drifts when air is lost, so add a rod lock or pilot check valve wherever a load must stay held. FB flange, CA/CB clevis, CR and FTC mountings cover the frame options, and the optional -S magnet enables CMSE or DMSE switches.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACE Guided Compact Cylinder TACE16X15 FAQ
At 0.5 MPa it pushes 100.5 N and pulls 75.4 N; at 0.7 MPa the push rises to 140.7 N (pull 105.6 N). The theoretical maximum at 1.0 MPa is 20.5 kgf. Operating pressure is 0.15-1.0 MPa (22-145 psi), proof pressure 1.5 MPa (215 psi), and speed 30-500 mm/s on air filtered to 40 um.
The ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, with a fixed TPU bumper at each end and FB, CA, CB, CR or FTC mounting choices. Position sensing requires the optional -S magnet code; without it, no CMSE or DMSE switch can be mounted. It is not a holding device, so use a rod lock or pilot check valve where a load must stay put.
