Airtac TACED Guided Compact Cylinder TACED100X100
The AirTAC Airtac TACED Guided Compact Cylinder TACED100X100 is a genuine double acting, double rod, non-rotating ISO 21287 compact air cylinder with a Ø100mm bore and 100mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ100 mm
- Stroke100 mm
- Port size1/4"
- Acting typeDouble acting, double rod, non-rotating
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACED Guided Compact Cylinder TACED100X100
Double acting and double rod, the TACED100X100 pushes a 100 mm piston through a 100 mm stroke with a rod leaving both covers, so the force is identical in each direction: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa. Twin guide rods on the yoke keep the tooling from rotating and carry side load, so a heavy press plate or lifting fixture stays square without an external guide. The fixed TPU bumper at each end absorbs end-of-stroke shock.
The hard-anodized aluminium body is an ISO 21287 compact build that saves about 50% of the mounting length of an ISO 15552 profile cylinder, letting this 100 mm bore fit inside guards and gantries where a full-length body will not. Air supply is 0.15-1.0 MPa (22-145 psi) with 1.5 MPa (215 psi) proof, speed runs 30-500 mm/s, and the rod is S45C steel with hard chrome, female M12x1.75 thread. Ports are 1/4" PT. Plan on roughly 2260 N (about 230 kgf) of usable work at 0.5 MPa, or lift about 192 kg vertically with a 2:1 margin.
Airtac TACED Guided Compact Cylinder TACED100X100 Technical Specifications
| Model | Airtac TACED Guided Compact Cylinder TACED100X100 |
|---|---|
| Series | TACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, non-rotating |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 100 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used). Twin guide rods carry the side load and stop the tooling rotating.
Model Code: Airtac TACED Guided Compact Cylinder TACED100X100
| TACED | ISO 21287 compact cylinder (double-rod non-rotating (twin-guide yoke)). |
|---|---|
| 100 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACED Guided Compact Cylinder TACED100X100 Is Used
Baling press platen
Equal 3769.9 N force in both directions lets one cylinder compact and retract a baling platen on the same stroke, with the twin guide yoke keeping the platen level against uneven bale resistance.
Pallet elevator carriage
A 100 mm bore lifting about 192 kg vertically with a 2:1 margin suits a pallet transfer carriage, and the non-rotating guide rods stop the carriage twisting on its guides.
Foundry gate actuator
The compact ISO 21287 body halves the mounting length of an ISO 15552 profile cylinder, so a heavy sand-gate slide can be driven inside a tight foundry shroud at 30-500 mm/s.
Is the Airtac TACED Guided Compact Cylinder TACED100X100 the Right Cylinder?
At 3769.9 N per direction this is the top of the range: a TACED63X100 gives 1458.1 N if the load is lighter, and there is no larger standard bore in the series. Because it does not hold position when air is lost, add a rod lock or pilot check valve for a suspended load. The FB flange, CA, CB, CR and FTC mountings cover frame and fixture needs, and order the -S code if you want the optional magnet for CMSE / DMSE switches - without -S no magnet is fitted.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACED Guided Compact Cylinder TACED100X100 FAQ
Yes - the double-rod design means both directions see the rod-side area. Output is 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa in either direction, with a maximum of 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), speed 30-500 mm/s, port 1/4" PT, female rod thread M12x1.75.
The ISO 21287 aluminium body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so a 100 mm bore fits where a long-body cylinder cannot. Each end carries a fixed TPU bumper that decelerates the piston at the ends of travel only; it never locks or holds a load, so use a rod lock or pilot check valve where a suspended position must be kept. The optional -S magnet enables CMSE / DMSE switches.
