Airtac TACED Guided Compact Cylinder TACED100X30
The AirTAC Airtac TACED Guided Compact Cylinder TACED100X30 is a genuine double acting, double rod, non-rotating ISO 21287 compact air cylinder with a Ø100mm bore and 30mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ100 mm
- Stroke30 mm
- Port size1/4"
- Acting typeDouble acting, double rod, non-rotating
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACED Guided Compact Cylinder TACED100X30
This is a double acting, double rod compact cylinder built to ISO 21287: a rod leaves both covers, so the 100 mm bore delivers the same 3769.9 N at 0.5 MPa (5277.9 N at 0.7 MPa) whether it extends or retracts. Twin guide rods on the yoke stop the tooling rotating and carry side load, so a heavy press plate or clamp arm stays square without an external guide. The hard-anodized aluminium body pairs with an S45C hard-chrome plated 20 mm rod, and a fixed TPU bumper at each end absorbs end-of-stroke shock.
The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, which matters when a 30 mm stroke must fit inside a guarded weld fixture or a dense palletizing gantry. For sizing real work, plan on roughly 2262 N of usable force at 0.5 MPa, and expect about 192 kg of vertical lift with a 2:1 margin. Air supply is 0.15-1.0 MPa (22-145 psi), speed runs 30-500 mm/s, and the optional -S magnet enables CMSE / DMSE switches; without -S no magnet is fitted.
Airtac TACED Guided Compact Cylinder TACED100X30 Technical Specifications
| Model | Airtac TACED Guided Compact Cylinder TACED100X30 |
|---|---|
| Series | TACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 30 mm |
| Acting type | Double acting, double rod, non-rotating |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 100 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used). Twin guide rods carry the side load and stop the tooling rotating.
Model Code: Airtac TACED Guided Compact Cylinder TACED100X30
| TACED | ISO 21287 compact cylinder (double-rod non-rotating (twin-guide yoke)). |
|---|---|
| 100 | Bore size in mm. |
| ×30 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACED Guided Compact Cylinder TACED100X30 Is Used
Weld fixture clamping
The equal 3769.9 N clamp and release force plus a 30 mm stroke suits heavy weld fixtures where the twin guide yoke keeps the clamp shoe square over the joint.
Palletizing push-off
A short 30 mm kick with about 2262 N of usable force at 0.5 MPa squares cartons on a palletizer conveyor, and the compact body fits between guard rails.
Bearing press assist
With roughly 192 kg of vertical lift capacity at a 2:1 margin, the 100 mm bore handles light press and ejection work on assembly benches where space is tight.
Is the Airtac TACED Guided Compact Cylinder TACED100X30 the Right Cylinder?
At 3769.9 N per direction this is the top of the ACE compact range. If your load needs under 2356 N at 0.5 MPa, the 80 mm bore (2356.2 N) saves space; there is no larger ACE bore, so step up to a different series beyond that. The 30 mm stroke sits well inside the 300 mm maximum standard stroke for bore 100. Note that the piston drifts if air is lost - for a held load add a rod lock or pilot check valve. Mounting is FB flange, rod end is female M12x1.75, ports are 1/4" PT, and the -S code is required if you want CMSE / DMSE switch positions.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACED Guided Compact Cylinder TACED100X30 FAQ
Yes - because a rod exits both covers, both sides see the rod-side area. Output is 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, equal on extend and retract, with a maximum of 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), speed 30-500 mm/s, temperature -20 to +70 C on air filtered to 40 um.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so a 30 mm stroke cylinder fits inside guarded cells and tight gantries. The twin guide rods on the yoke prevent load rotation and carry side load, the fixed TPU bumpers absorb end-of-stroke shock at both ends, and FB flange mounting with a female M12x1.75 rod thread is standard. Add the optional -S magnet if you need CMSE / DMSE switch feedback.
