Airtac TACED Guided Compact Cylinder TACED100X70
The AirTAC Airtac TACED Guided Compact Cylinder TACED100X70 is a genuine double acting, double rod, non-rotating ISO 21287 compact air cylinder with a Ø100mm bore and 70mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ100 mm
- Stroke70 mm
- Port size1/4"
- Acting typeDouble acting, double rod, non-rotating
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACED Guided Compact Cylinder TACED100X70
Double acting and double rod, the TACED100X70 pushes a rod out of both covers of its ISO 21287 compact body, so the 100 mm bore delivers an identical 3769.9 N in each direction at 0.5 MPa (5277.9 N at 0.7 MPa). Because both strokes act on the rod-side area, there is no push-versus-pull gap to design around. Twin guide rods on the yoke stop the tooling rotating and carry side load, keeping a press plate or gripper square without an external guide.
The hard-anodized aluminium body with an S45C hard-chrome-plated 20 mm rod runs on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi), 30-500 mm/s, with a fixed TPU bumper at each end. In practice, plan on roughly 2262 N of usable work at 0.5 MPa, and expect about 192 kg of vertical lift with a 2:1 margin. The short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, and the optional -S magnet enables CMSE / DMSE switches.
Airtac TACED Guided Compact Cylinder TACED100X70 Technical Specifications
| Model | Airtac TACED Guided Compact Cylinder TACED100X70 |
|---|---|
| Series | TACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 70 mm |
| Acting type | Double acting, double rod, non-rotating |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 100 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used). Twin guide rods carry the side load and stop the tooling rotating.
Model Code: Airtac TACED Guided Compact Cylinder TACED100X70
| TACED | ISO 21287 compact cylinder (double-rod non-rotating (twin-guide yoke)). |
|---|---|
| 100 | Bore size in mm. |
| ×70 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACED Guided Compact Cylinder TACED100X70 Is Used
Baler ram return
The 3769.9 N return stroke matches the push, so a scrap-baler or compacting ram retracts with full force instead of the weak rod-side pull of a single-rod cylinder.
Pallet clamp plate
Twin guide rods keep a 70 mm-stroke clamp plate square over a pallet in a warehouse press station, carrying side load without extra guide columns.
Foundry gate actuator
A casting-line sand gate opens and closes with equal 5277.9 N at 0.7 MPa, and the compact body slots into the tight space beside the mould line.
Is the Airtac TACED Guided Compact Cylinder TACED100X70 the Right Cylinder?
At 3769.9 N per side, the 100 mm bore sits at the top of the TACED range; step down to the 80 mm bore (2356.2 N) for lighter clamping or up from the 63 mm bore (1458.1 N) when 70 mm of stroke must move heavier tooling. The piston drifts if air is lost, so add a rod lock or pilot check valve where a load must stay held. Order the -S code if CMSE / DMSE position switches are needed, and specify FB flange or CA/CB/CR/FTC hardware; the female M12x1.75 rod thread and PT ports are fixed on this variant.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACED Guided Compact Cylinder TACED100X70 FAQ
Yes. The double-rod design exposes the rod-side area on both strokes, so the 100 mm bore gives 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa in each direction, equal push and pull. At 1.0 MPa the peak is 768.8 kgf. Operating range is 0.15-1.0 MPa (22-145 psi) with 1.5 MPa (215 psi) proof pressure, speed 30-500 mm/s, and a fixed TPU bumper at each end.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so the 70 mm stroke fits shallow jigs and guards. The magnet is not fitted as standard: order the -S code to enable CMSE / DMSE reed or solid-state switches for end-of-stroke sensing. The rod ends in a female M12x1.75 thread, ports are 1/4" PT, and FB, CA, CB, CR and FTC mountings are available.
