Airtac TACED Guided Compact Cylinder TACED100X75
The AirTAC Airtac TACED Guided Compact Cylinder TACED100X75 is a genuine double acting, double rod, non-rotating ISO 21287 compact air cylinder with a Ø100mm bore and 75mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ100 mm
- Stroke75 mm
- Port size1/4"
- Acting typeDouble acting, double rod, non-rotating
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACED Guided Compact Cylinder TACED100X75
A double acting, double-rod compact cylinder built to ISO 21287, the TACED100X75 pushes a 100 mm bore through a 75 mm stroke with a rod leaving both covers. Because both sides work on the rod-side area, output is identical in each direction: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, with a peak of 768.8 kgf at 1.0 MPa. Twin guide rods on the yoke stop the tooling rotating and take side load, so a press plate or gripper stays square without an external guide.
The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, which matters in heavy jigs and gantries where every millimetre counts. In practice, plan on roughly 2262 N of usable work at 0.5 MPa (about 0.6 of the rating), which is enough to lift about 192 kg vertically with a 2:1 margin. The hard-anodized aluminium body carries a hard-chrome plated S45C rod, fixed TPU bumpers absorb end-of-stroke shock at both ends, and the optional -S magnet enables CMSE / DMSE switches.
Airtac TACED Guided Compact Cylinder TACED100X75 Technical Specifications
| Model | Airtac TACED Guided Compact Cylinder TACED100X75 |
|---|---|
| Series | TACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 75 mm |
| Acting type | Double acting, double rod, non-rotating |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 100 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used). Twin guide rods carry the side load and stop the tooling rotating.
Model Code: Airtac TACED Guided Compact Cylinder TACED100X75
| TACED | ISO 21287 compact cylinder (double-rod non-rotating (twin-guide yoke)). |
|---|---|
| 100 | Bore size in mm. |
| ×75 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACED Guided Compact Cylinder TACED100X75 Is Used
Heavy jig clamping
The 3769.9 N double-direction force clamps steel weldments in machining fixtures from either side, with the twin guide yoke keeping the clamp plate square to the part.
Press-fit staking
A 75 mm stroke covers short press and staking operations on bearing bushes and dowels, where about 2262 N of practical working force at 0.5 MPa does the job.
Pallet gate actuation
In warehouse conveyor lines the compact body swings heavy safety gates and stops, lifting about 192 kg vertically with a 2:1 margin at 0.5 MPa.
Is the Airtac TACED Guided Compact Cylinder TACED100X75 the Right Cylinder?
At this force class the TACED100X75 sits near the top of the range: 3769.9 N per direction at 0.5 MPa. If your load needs under 2356.2 N, step down to the bore 80 TACED80; if you need more than 5277.9 N at 0.7 MPa, parallel two cylinders or move to a larger frame. Note it drifts when air is lost, so add a rod lock or pilot check valve for held loads.
Ports are 1/4" (PT thread standard, G available), the rod end is female M12x1.75, and FB flange mounting suits fixed jigs. Order the -S code if you want position feedback via CMSE / DMSE switches; without it there is no magnet in the piston.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACED Guided Compact Cylinder TACED100X75 FAQ
Output is equal in both directions because a rod exits both covers and both sides see the rod-side area. At 0.5 MPa it delivers 3769.9 N, at 0.7 MPa it delivers 5277.9 N, and the maximum at 1.0 MPa is 768.8 kgf. Operating pressure is 0.15-1.0 MPa (22-145 psi) with a 1.5 MPa (215 psi) proof pressure, speed is 30-500 mm/s, and the bore is 100 mm with a 20 mm rod.
It is an ISO 21287 compact cylinder whose short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it suits tight machine frames. FB flange mounting is available, the port is 1/4" (PT or G thread), and the rod end is female M12x1.75. A fixed TPU bumper at each end absorbs end-of-stroke energy but is not adjustable. Position sensing needs the optional -S magnet ordered with CMSE / DMSE switches; without -S no magnet is fitted.
