This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ACED100X10 — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ACED100X10 in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPD Double Rod Compact Cylinder ACPD100X10
The AirTAC Airtac ACPD Double Rod Compact Cylinder ACPD100X10 is a double acting, double rod DIN-standard tight/compact air cylinder with a Ø100mm bore and 10mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACED100X10 (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke10 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM16×1.5
- StatusDiscontinued → ACED100X10
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPD Double Rod Compact Cylinder ACPD100X10
A double acting compact cylinder with a rod leaving both covers, the ACPD100X10 delivers 3681.6 N in either direction at 0.5 MPa (5154.2 N at 0.7 MPa) because both strokes work on the rod-side area of its 100 mm bore. The through-rod resists rotation and side load, gives a symmetric mount, and the rear rod can carry a sensor flag. Its short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into presses, clamping bridges and gantries where a full-length body will not fit.
The hard-anodized aluminium body carries an S45C hard-chrome rod, fixed TPU bumpers at each end, and a 1/4" port; it runs on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi) with speeds of 30-500 mm/s. Plan on roughly 2209 N (about 225 kg) of real work at 0.5 MPa rather than the full rating, and note the piston drifts if air is lost, so add a rod lock or pilot check for a held load. This model is discontinued; the current-production drop-in is the ACED100X10, so confirm ISO 21287 mounting dimensions before swapping.
Airtac ACPD Double Rod Compact Cylinder ACPD100X10 Technical Specifications
| Model | Airtac ACPD Double Rod Compact Cylinder ACPD100X10 |
|---|---|
| Series | ACPD DIN compact cylinder (discontinued) |
| Replacement | ACED100X10 |
| Bore size | Ø100 mm |
| Stroke | 10 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACED100X10 (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3682 N |
| 0.7 MPa | 5154 N |
| Max (@1.0 MPa) | 751 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACPD Double Rod Compact Cylinder ACPD100X10
| ACPD | DIN compact cylinder (double-rod, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ACPD Double Rod Compact Cylinder ACPD100X10 Is Used
Short-stroke press station
A 10 mm throw pushing 3681.6 N at 0.5 MPa suits marking, staking or snap-fit presses on electronics assembly lines where the compact body fits inside the press frame.
Symmetric clamping bridge
With a rod on each cover, one cylinder can clamp a fixture from both faces with equal 3681.6 N force, ideal for machining jigs holding aluminium housings.
End-of-travel flag sensing
The rear through-rod can drive a flag past a CMSE or DMSE switch (when the -S magnet is ordered) to confirm full retraction on packaging machine tooling.
Replacing the Airtac ACPD Double Rod Compact Cylinder ACPD100X10 with the ACED100X10
At 10 mm stroke this is a short-throw, high-force pick: choose the ACPD100X10 when you need 3681.6 N both ways at 0.5 MPa in a tight envelope. If the job needs less, the 80 mm bore gives 2356.2 N at 0.5 MPa; if more, step up is not available in this family, so consider a larger ACE bore. Mounting is FA/FB flange or LB foot on the ISO 21287 face, with I/Y rod knuckles to suit. The magnet is not fitted on this code; order the -S variant if you want CMSE / DMSE switches. Replacement: ACED100X10.
Replacement checklist
- ✓ Current-production ACE → ACED100X10
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPD Double Rod Compact Cylinder ACPD100X10 FAQ
Because a rod exits both covers, force is equal in both directions: 3681.6 N at 0.5 MPa and 5154.2 N at 0.7 MPa on the rod-side area of the 100 mm bore, with a maximum of 750.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof pressure 1.5 MPa (215 psi), speed 30-500 mm/s, port 1/4", rod thread M16x1.5 female.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, with fixed TPU bumpers at both ends and FA/FB flange or LB foot mounting. The ACPD100X10 is discontinued; the current-production drop-in is the ACED100X10 in the same bore, stroke and force class - confirm the ISO 21287 mounting dimensions before swapping.
