This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ACED100X10B — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ACED100X10B in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPD Double Rod Compact Cylinder ACPD100X10B
The AirTAC Airtac ACPD Double Rod Compact Cylinder ACPD100X10B is a double acting, double rod DIN-standard tight/compact air cylinder with a Ø100mm bore and 10mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACED100X10B (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke10 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM16×1.5
- StatusDiscontinued → ACED100X10B
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPD Double Rod Compact Cylinder ACPD100X10B
A double acting compact cylinder with a rod leaving both covers, the ACPD100X10B pushes and pulls with identical force because each stroke works on the rod-side area: 3681.6 N at 0.5 MPa and 5154.2 N at 0.7 MPa, equal in both directions. The 100 mm bore drives a 25 mm hard-chrome S45C rod, and the male rod thread (B code) suits external rod couplings and knuckles. The short ISO 21287-class body saves roughly 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into heavy presses and gantries where a full-length body will not fit.
The through-rod resists rotation and side load and gives a symmetric fixture mount, while the rear rod can carry a sensor flag on a mirrored bracket. Fixed TPU bumpers pad both ends of travel, and speed spans 30-500 mm/s on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi). Plan on about 2209 N of usable push at 0.5 MPa - roughly 188 kg lifted vertically with a 2:1 margin - rather than the full rating. Note this model is discontinued; the current-production drop-in is the ACED100X10, so confirm ISO 21287 mounting dimensions before swapping.
Airtac ACPD Double Rod Compact Cylinder ACPD100X10B Technical Specifications
| Model | Airtac ACPD Double Rod Compact Cylinder ACPD100X10B |
|---|---|
| Series | ACPD DIN compact cylinder (discontinued) |
| Replacement | ACED100X10B |
| Bore size | Ø100 mm |
| Stroke | 10 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACED100X10B (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3682 N |
| 0.7 MPa | 5154 N |
| Max (@1.0 MPa) | 751 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACPD Double Rod Compact Cylinder ACPD100X10B
| ACPD | DIN compact cylinder (double-rod, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ACPD Double Rod Compact Cylinder ACPD100X10B Is Used
Short-stroke press stamping
A 10 mm stroke with 3681.6 N at 0.5 MPa suits marking or staking heads on aluminium extrusion ends where the die travel is minimal and cycle rate is high.
Symmetric push-pull fixture
The double rod delivers equal 5154.2 N force at 0.7 MPa on both strokes, ideal for a machining fixture that clamps, retracts and clamps again with one valve.
Heavy part eject on assembly lines
With about 188 kg of vertical lift capacity at a 2:1 margin, the 100 mm bore ejects cast housings from a conveyor-mounted nest in tight headroom.
Replacing the Airtac ACPD Double Rod Compact Cylinder ACPD100X10B with the ACED100X10B
At 3681.6 N per side at 0.5 MPa, the 100 mm bore is the top of the ACPD range; step down to the 80 mm bore (2356.2 N) for lighter clamping or stay here for heavy press and lift work. The 10 mm stroke is well inside the 300 mm max standard stroke for this bore. The male rod thread (B) pairs with I/Y knuckles on the ISO 21287 face, and FA/FB flange or LB foot mounts bolt straight on. This cylinder drifts when air is lost, so add a rod lock or pilot check for a held load. No magnet is fitted on this code - order the -S variant if CMSE / DMSE switches are needed. Discontinued: specify the ACED100X10 as the current replacement.
Replacement checklist
- ✓ Current-production ACE → ACED100X10B
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPD Double Rod Compact Cylinder ACPD100X10B FAQ
Because a rod exits both covers, force is equal in both directions: 3681.6 N at 0.5 MPa and 5154.2 N at 0.7 MPa, on the rod-side area. At the full 1.0 MPa rating the cylinder reaches about 750.8 kgf. Operating pressure is 0.15-1.0 MPa (22-145 psi) with a 1.5 MPa (215 psi) proof pressure, and speed runs 30-500 mm/s.
The hard-anodized aluminium body follows the short ISO 21287-class format, saving about 50% of the mounting length of an ISO 15552 profile cylinder, with a fixed TPU bumper at each end and a 1/4" port. This ACPD model is discontinued; the current-production drop-in is the ACED100X10 - confirm the ISO 21287 mounting dimensions before swapping.
