This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ACED100X10SB — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ACED100X10SB in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPD Double Rod Compact Cylinder ACPD100X10SB
The AirTAC Airtac ACPD Double Rod Compact Cylinder ACPD100X10SB is a double acting, double rod DIN-standard tight/compact air cylinder with a Ø100mm bore and 10mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACED100X10SB (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke10 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM16×1.5
- StatusDiscontinued → ACED100X10SB
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPD Double Rod Compact Cylinder ACPD100X10SB
Double acting with a rod leaving both covers, the ACPD100X10SB pushes and pulls with identical force - 3681.6 N each way at 0.5 MPa and 5154.2 N at 0.7 MPa - because both strokes work on the rod-side area. The 10 mm stroke suits short indexing moves, and the through-rod resists rotation and side load while the rear rod can carry a sensor flag. A fixed TPU bumper sits at each end and the speed range is 30-500 mm/s.
The hard-anodized aluminium body follows the ISO 21287 short format, cutting roughly 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into dense presses and clamping stations. For planning, count on about 2200 N of real work at 0.5 MPa - roughly 225 kg of vertical lift with margin - rather than the full rating. Note this model is discontinued: the current drop-in is ACED100X10, so confirm ISO 21287 mounting dimensions before swapping.
Airtac ACPD Double Rod Compact Cylinder ACPD100X10SB Technical Specifications
| Model | Airtac ACPD Double Rod Compact Cylinder ACPD100X10SB |
|---|---|
| Series | ACPD DIN compact cylinder (discontinued) |
| Replacement | ACED100X10SB |
| Bore size | Ø100 mm |
| Stroke | 10 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACED100X10SB (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3682 N |
| 0.7 MPa | 5154 N |
| Max (@1.0 MPa) | 751 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACPD Double Rod Compact Cylinder ACPD100X10SB
| ACPD | DIN compact cylinder (double-rod, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ACPD Double Rod Compact Cylinder ACPD100X10SB Is Used
Short-stroke press station
The 10 mm stroke and 3681.6 N both-way force suit a compact crimping or staking head on an electronics assembly line where a full-length cylinder cannot fit.
Symmetric push-pull fixture
With equal force in each direction and a male-threaded rod on both ends, one cylinder can clamp a machined housing from either side in a CNC pallet fixture.
Position-flagged gantry stop
The rear through-rod carries a flag for CMSE or DMSE switches (this -S model has the magnet), confirming a 10 mm indexing move on an automated transfer unit.
Replacing the Airtac ACPD Double Rod Compact Cylinder ACPD100X10SB with the ACED100X10SB
At 3681.6 N per side, the 100 mm bore is the top of the ACPD range; if your load needs less, the 80 mm bore delivers 2356.2 N at 0.5 MPa on the same short body. The 10 mm stroke is well inside the 300 mm standard maximum for this bore, so no made-to-order build is required. This unit carries the optional -S magnet, so CMSE or DMSE switches can be mounted for end-position sensing, and the B code gives a male 25 mm rod thread with a 1/4" PT port. A plain double-rod cylinder drifts when air is lost, so add a rod lock or pilot check if the load must stay put. Order ACED100X10 as the current-production replacement.
Replacement checklist
- ✓ Current-production ACE → ACED100X10SB
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPD Double Rod Compact Cylinder ACPD100X10SB FAQ
Yes - the double-rod design means both strokes use the rod-side area, so output is equal each way: 3681.6 N at 0.5 MPa and 5154.2 N at 0.7 MPa, with a maximum of 750.8 kgf at 1.0 MPa. Operating pressure is 0.15-1.0 MPa (22-145 psi) and proof pressure is 1.5 MPa (215 psi).
AirTAC no longer produces the ACPD family. The current drop-in is ACED100X10 (swap the P for an E), an ISO 21287 compact cylinder in the same 100 mm bore, 10 mm stroke and force class. Because the ACP is DIN-standard, confirm the ISO 21287 mounting dimensions before swapping it into an existing fixture.
