This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ACED100X110 — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ACED100X110 in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPD Double Rod Compact Cylinder ACPD100X110
The AirTAC Airtac ACPD Double Rod Compact Cylinder ACPD100X110 is a double acting, double rod DIN-standard tight/compact air cylinder with a Ø100mm bore and 110mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACED100X110 (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke110 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM16×1.5
- StatusDiscontinued → ACED100X110
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPD Double Rod Compact Cylinder ACPD100X110
Double acting with a rod leaving both covers, the ACPD100X110 is a DIN-standard compact cylinder: 100 mm bore, 110 mm stroke, 25 mm rod on each end and a 1/4" port. Because both strokes work on the rod-side area, output is identical in each direction - 3681.6 N at 0.5 MPa and 5154.2 N at 0.7 MPa. The hard-anodized aluminium body with an S45C hard-chrome rod runs on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi), 30-500 mm/s, and a fixed TPU bumper sits at each end. This model is discontinued; the current-production successor is the ACED100X110.
In practice, plan on roughly 2209 N (about 225 kg of push) for real work at 0.5 MPa instead of the full rating, and expect it to lift about 187 kg vertically with a 2:1 margin. The short ISO 21287-class body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it suits wide gantries and heavy clamping fixtures where space is tight. The through-rod resists rotation and side load, and the rear rod can carry a sensor flag; FA/FB flange and LB foot mounts bolt to the standard face. Note that with no air the piston drifts - use a rod lock or pilot check where a load must be held.
Airtac ACPD Double Rod Compact Cylinder ACPD100X110 Technical Specifications
| Model | Airtac ACPD Double Rod Compact Cylinder ACPD100X110 |
|---|---|
| Series | ACPD DIN compact cylinder (discontinued) |
| Replacement | ACED100X110 |
| Bore size | Ø100 mm |
| Stroke | 110 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACED100X110 (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3682 N |
| 0.7 MPa | 5154 N |
| Max (@1.0 MPa) | 751 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACPD Double Rod Compact Cylinder ACPD100X110
| ACPD | DIN compact cylinder (double-rod, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ACPD Double Rod Compact Cylinder ACPD100X110 Is Used
Heavy pallet press station
Equal 3681.6 N force on both strokes lets one cylinder press a pallet into a shipping crate on the forward stroke and eject it on the return, with the 110 mm stroke clearing a 100 mm-deep part.
Bottling line pusher gate
The through-rod keeps the pusher bar square under side load as it diverts 150 kg crates off a conveyor, and the rear rod carries a flag for a position sensor when the optional -S magnet is ordered.
Die-cart lift column
A symmetric double-rod mount lifts about 187 kg of tooling vertically with a 2:1 margin at 0.5 MPa, and the short body fits inside a shallow machine base where a full-length cylinder will not.
Replacing the Airtac ACPD Double Rod Compact Cylinder ACPD100X110 with the ACED100X110
At 3681.6 N per side at 0.5 MPa, this 100 mm bore sits at the top of the ACPD range; the 80 mm bore below it delivers 2356.2 N, so step down if your clamp or press needs less. Stroke 110 mm is well inside the 300 mm maximum standard stroke for this bore, so no made-to-order build is required. Choose the -S code if you want the optional magnet for CMSE / DMSE switches - without it there is no magnet at all. Female M16x1.5 rod thread and PT ports are standard here; add B for a male rod thread. This unit is discontinued, so spec the ACED100X110 as the drop-in and confirm the ISO 21287 mounting dimensions before swapping.
Replacement checklist
- ✓ Current-production ACE → ACED100X110
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPD Double Rod Compact Cylinder ACPD100X110 FAQ
Output is equal both ways because a rod exits each cover and both strokes use the rod-side area: 3681.6 N at 0.5 MPa, 5154.2 N at 0.7 MPa, with a maximum of 750.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), speed 30-500 mm/s, temperature -20 to +70 C, air filtered to 40 um. The 110 mm stroke is standard for the 100 mm bore (max standard 300 mm).
Order the ACED100X110, the current-production ISO 21287 successor: swap the P for an E and you get the same 100 mm bore, 110 mm stroke and force class in a matching short body. The ACP is DIN-standard, so confirm the ISO 21287 mounting dimensions against your fixture before swapping. If you need position sensing, the replacement also takes its magnet as an option for CMSE / DMSE switches.
