This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ATE100X10SB — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ATE100X10SB in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ATP Single Acting Port Compact Cylinder ATP100X10SB
The AirTAC Airtac ATP Single Acting Port Compact Cylinder ATP100X10SB is a single acting, pull (spring return) DIN-standard tight/compact air cylinder with a Ø100mm bore and 10mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ATE100X10SB (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke10 mm
- Port size1/4"
- Acting typeSingle acting, pull (spring return)
- Rod threadM16×1.5
- StatusDiscontinued → ATE100X10SB
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ATP Single Acting Port Compact Cylinder ATP100X10SB
Single acting pull cylinder of the discontinued ATP family, spring extend: the spring pushes the rod out and compressed air retracts it, so the part is normally extended at rest and fails to the extended position when air is lost. At the 100 mm bore this version pulls 3395.3 N at 0.5 MPa and 4867.9 N at 0.7 MPa, both figures already net of the return spring, with a 10 mm stroke and a 25 mm rod carrying a male thread (the B code). Working pressure is 0.2-1.0 MPa (28-145 psi) and the spring needs at least 0.2 MPa of air to be overpowered.
The hard-anodized aluminium body keeps the mounting length roughly 50% shorter than an ISO 15552 profile cylinder, which is why this bore class fits deep clamping pockets and guarded assemblies where a full-length body will not reach. In practice, plan on about 2037 N of real work at 0.5 MPa rather than the full rating, and expect roughly 173 kg of vertical lift with a 2:1 margin. The S in the code means the optional -S magnet is fitted, so CMSE or DMSE switches can be bolted on for end-of-stroke signalling; fixed TPU bumpers sit at both ends. Production has ended - the current drop-in is ATE100X10, and you should confirm ISO 21287 mounting dimensions before swapping.
Airtac ATP Single Acting Port Compact Cylinder ATP100X10SB Technical Specifications
| Model | Airtac ATP Single Acting Port Compact Cylinder ATP100X10SB |
|---|---|
| Series | ATP DIN compact cylinder (discontinued) |
| Replacement | ATE100X10SB |
| Bore size | Ø100 mm |
| Stroke | 10 mm |
| Acting type | Single acting, pull (spring return) |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 25 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ATE100X10SB (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Pull force (spring return) |
|---|---|
| 0.5 MPa | 3395.3 N |
| 0.7 MPa | 4867.9 N |
Single-acting pull: the spring extends the rod; air retracts it. Forces already net the spring; minimum working pressure is 0.2 MPa.
Model Code: Airtac ATP Single Acting Port Compact Cylinder ATP100X10SB
| ATP | DIN compact cylinder (single-acting pull, spring-return, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ATP Single Acting Port Compact Cylinder ATP100X10SB Is Used
Clamp retraction on a CNC fixture
The spring holds the clamp open and air pulls 3395.3 N at 0.5 MPa to grip a cast aluminium housing during a 10 mm machining pass.
Fail-safe gate return on a bottling line
If air pressure drops, the spring extends the rod and the guide gate springs back to its home position, clearing the bottle path without operator action.
Lid release on a press shop pallet station
About 173 kg of vertical lift capability with a 2:1 margin lets the rod retract a steel pallet lid, with a DMSE switch confirming the retracted end.
Replacing the Airtac ATP Single Acting Port Compact Cylinder ATP100X10SB with the ATE100X10SB
Size against neighbours: the 80 mm bore pulls 2159.1 N at 0.5 MPa while this 100 mm bore reaches 3395.3 N, so step up only when the 80 mm unit is within about 60% of your need. Remember the spring returns the rod to its extended home on air loss and will not hold a mid-stroke position. Mounting brackets from the FA/FB flange, LB foot and CA/CB clevis family bolt straight to the face, and the fitted -S magnet lets you add CMSE or DMSE switches where signalling is required. Since ATP is discontinued, order ATE100X10 as the current-production equivalent and verify the ISO 21287 footprint first.
Replacement checklist
- ✓ Current-production ACE → ATE100X10SB
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ATP Single Acting Port Compact Cylinder ATP100X10SB FAQ
This 100 mm bore single acting pull cylinder gives 3395.3 N at 0.5 MPa and 4867.9 N at 0.7 MPa, both net of the return spring. The spring extends the rod and air retracts it, so a minimum of 0.2 MPa is needed to beat the spring, within a 0.2-1.0 MPa (28-145 psi) working band and 1.5 MPa (215 psi) proof pressure. Speed range is 50-500 mm/s over the 10 mm stroke, with a 25 mm male-thread rod and a 1/4" port.
Order ATE100X10, the current-production ISO 21287 successor: swap the P for an E and you get the same 100 mm bore, 10 mm stroke and force class in a short body that saves about 50% of the mounting length of an ISO 15552 profile cylinder. Because the ATP was built to a DIN-standard footprint, confirm the ISO 21287 mounting dimensions against your fixture before the swap. The ATE also accepts the optional -S magnet for CMSE / DMSE switches.
